Voltage/current converter SPYDER E-BATT series

powercompactall-in-one

Electronic battery converter SPYDER E-BATT
The SPYDER E-BATT is the lightest battery-powered portable concrete vibrator in its segment. It can be operated with either a backpack or a shoulder strap to improve handling and ergonomics. The battery is interchangeable with other ENAR E-BATT products, enabling continued work without interruptions.

Main features

• Suitable for vibrator heads with diameters 30, 38, 48 and 58 mm.
• Aluminium body with plastic end-caps and rubber protection.
• Lightweight and easy to transport; compatible with backpack or strap use.
• Battery charge indicator and base-closing lid to protect the battery from dirt and water.
• Stable voltage throughout the battery discharge phase.

Benefits

• Cordless — no mains connection required, reducing trip hazards and improving site safety.
• Lightweight and manageable — compact design for easier transport and use in confined areas.
• Eco-friendly — zero direct emissions and low noise levels.
• Zero maintenance — electronic conversion system without wear parts that require regular replacement.

Available models

• SPYDER E-BATT M38
• SPYDER E-BATT M5
• SPYDER E-BATT M6
• SPYDER E-BATT M30

Optional accessories

• Battery SPYDER E-BATT
• Extra charger SPYDER E-BATT

Applications
Designed to provide maximum freedom of movement, the SPYDER E-BATT is ideal for construction sites where agility and autonomy are decisive: work at height, locations without electrical access, or urban environments with noise and emission restrictions. The interchangeable battery enables uninterrupted vibration while the ergonomic, robust design ensures operator comfort and durability in demanding conditions.

Technical characteristics (table)
SPYDER E-BATT M38 | SPYDER E-BATT M5 | SPYDER E-BATT M6 | SPYDER E-BATT M30
AUTONOMY: 58 min | 47 min | 35 min | 110 min
DIAMETER: 38 mm | 48 mm | 58 mm | 30 mm
DIMENSIONS: 438 x 177 x 187 mm | 438 x 177 x 187 mm | 438 x 177 x 187 mm | 438 x 177 x 187 mm
WEIGHT: 13.8 kg | 17.9 kg | 19.9 kg | 12 kg

Characteristics / technical specifications

• Series: SPYDER E-BATT
• Models available: SPYDER E-BATT M38, M5, M6, M30
• Available diameters: 30 mm, 38 mm, 48 mm, 58 mm
• Autonomy (depending on model): 35 to 110 minutes
• Dimensions (all models): 438 x 177 x 187 mm
• Weight (depending on model): 12 kg to 19.9 kg
• Body: aluminium with plastic end-caps and rubber protection
• Battery: interchangeable with other ENAR E-BATT products; charge indicator; protective base lid
• Power supply: battery (cordless operation)
• Electronic conversion ensuring stable output voltage during discharge
