Blind rivet - SR1913 - Essentra Components - countersunk head / nylon / black

Characteristics

Type

blind

Head

countersunk head

Material

nylon

Color

black

Other characteristics

expanding

Body diameter

4 mm, 7.5 mm, 8 mm
(0.16 in, 0.3 in, 0.31 in)

Min. and max. grip range

Max.: 8 mm
(0.31 in)

Min.: 3 mm
(0.12 in)

Hole diameter

4 mm, 7.5 mm, 8 mm
(0.2 in, 0.3 in, 0.3 in)

Length

7.8 mm, 11.6 mm, 17.5 mm, 21.8 mm
(0.31 in, 0.46 in, 0.69 in, 0.86 in)

Head diameter

7.5 mm, 12.7 mm, 19 mm
(0.3 in, 0.5 in, 0.75 in)

Description

Product Details
Fir Tree Rivet that features a double ended design; allowing for the blind fixing of two panels from the centre, so that no fastener head is visible. The simple design allows the rivet to be pressed neatly into position and provides a clean finish to your application. Ideal for joining and securing soft sheet materials, such as; board, rubber and secondary panels. More durable than using adhesive, provides high pull out loads and they are quick and easy to install by hand.

Material: Nylon 6/6
Colour: Black
UL94 V2 Material Flammability Rating

Series Code
SR1913
Product Range
Rivets & Panel Fastening
Product Set
Plastic Rivets
Material
Nylon
Type
Barbed Rivets

Variants (SKUs) and Key Specifications
SKU: 495220
Price: £0.506
Compatible Hole Diameter: 8.0 mm (0.315 in)
Head Diameter: 12.7 mm (0.5 in)
Head Height: 1.1 mm (0.043 in)
Anchor Length A: 11.6 mm (0.457 in)
Anchor Length B: 21.8 mm (0.858 in)

SKU: 495218
Price: £0.4493
Compatible Hole Diameter: 4.0 mm (0.157 in)
Head Diameter: 7.5 mm (0.295 in)
Head Height: 1.8 mm (0.071 in)
Panel Thickness Range: 6.3 - 2.6 mm (0.248 - 0.102 in)
Anchor Length A: 7.8 mm (0.307 in)

SKU: 495219
Price: £0.428
Compatible Hole Diameter: 7.5 mm (0.295 in)
Head Diameter: 19.0 mm (0.748 in)
Head Height: 1.0 mm (0.039 in)
Panel Thickness Range: 3.0 - 8.00 mm (0.118 - 0.315 in)
Anchor Length A: 17.5 mm (0.689 in)
