Screw-in cable tie mount 10009253
polyamide

Screw-in cable tie mount - 10009253 - Essentra Components - polyamide
Screw-in cable tie mount - 10009253 - Essentra Components - polyamide
Screw-in cable tie mount - 10009253 - Essentra Components - polyamide - image - 2
Add to favorites
Compare this product
Go to the Essentra Components website for more information

Characteristics

Type
screw-in
Material
polyamide

Description

Overview
  • Push-fit, removable cable tie mount designed to secure cable ties in pre-drilled panels. Available in multiple mounting variants and sizes to fit different panel thicknesses and tie widths.


Variants / Example references:
  • FTH-39-1-01 (10009543) — Nylon 6/6, natural color, mounting: push-in, panel thickness range: 1.0 - 4.5 mm.
  • FTH-14S-01BK-M (10009321) — PA black, mounting: screw & rivet, compatible tie width: 8.2 mm (0.323 in), overall height 9.8 mm, overall length 22.2 mm.
  • 460336 (10246115) — Nylon 6/6 natural, mounting: screw, compatible tie width: 2.4 - 4.8 mm (0.094 - 0.189 in), overall height 7.0 mm.
  • FTH-13R-19-M (10009246) — Nylon 6/6 natural, mounting: screw, compatible tie width: 5.3 mm (0.209 in), overall height 7.1 mm, overall length 15.2 mm.


Technical characteristics / specifications:
  • Series: SR2022.
  • Material: Polyamide 66 (Nylon 6/6).
  • Material flammability rating: UL94 V-2 (where specified).
  • Available mounting methods: Clip-in / Push-fit, Push-in, Screw, Rivet, Screw & rivet combinations depending on variant.
  • Panel thickness ranges (examples): 0.039 - 0.177 in (1.0 - 4.5 mm), 0.031 - 0.118 in (0.8 - 3.0 mm), 0.047 - 0.11 in (1.2 - 2.8 mm) — variant-dependent.
  • Compatible cable tie widths (examples): from 2.0 mm up to 13.3 mm depending on variant (e.g. 2.4 - 4.8 mm, 5.3 mm, 8.2 mm, 9.0 mm, 13.0 mm).
  • Observed colors: Natural (beige / natural nylon), Black (PA black).
  • Typical heights and lengths (examples): heights ~7.0 - 9.8 mm, lengths ~15.0 - 22.2 mm depending on reference.
  • Number of variants listed on product page: several dozen (detailed SKU table available in variant section).
