Truck-mounted crane F30CY.0 series

boomtelescopicloading

The Fassi F30CY active is a compact and functional crane designed for everyday light lifting operations. With a maximum moment of 2.65 tm and a hydraulic outreach of up to 6.45 metres, it guarantees precision and reliability even in restricted spaces. Equipped with the Walvoil monobloc hydraulic distributor, as well as pressure gauge and immediate stop systems, it offers optimal safety and control. The active configuration (.0) simplifies operations, while 370° rotation with rack and pinion ensures smoothness and manoeuvrability with every movement. A security system that detects if the lateral extension supports of the outriggers are fully retracted, both for manually and hydraulically extendable outrigger supports. Linked to the height check system of the crane, at rest in the transport position, it is completed by a visualizer with visual and acoustic alarm, to install on the dashboard of the vehicle cab. A Fassi system that guarantees an exceptional extension/retraction speed of the telescopic booms, built up by a set of equally powerful independent rams, linked in series connection and activated by a single control. Special independent fixing system of the extension rams to guarantee high vertical lifting performances. Ultra high strength steel used for the construction of the Fassi structural components, with a high elastic limit, increases structural strength and resistance of the components and at the same time reduces the weight of the crane, to the benefit of the loading capacity of the vehicle which increases.
