Mobile pallet scale WFP series

stainless steelwith separate indicatorsteel

Scales with U profile, available in painted or AISI 304 stainless steel. CE-M approvable. WFP-PRO SERIES SCALES U-PROFILE - TRANSPORTABLE - INDICATOR EXCLUDED Pallet weighing scales with low U-profile. They are suitable for rapid weighing of goods on pallets and can be easily handled in workshops and warehouses. CE-M approved. The scales are available in RAL 5007 painted steel or in AISI 304 stainless steel. TECHNICAL FEATURES: - Functioning with 4 shear-beam load cells approved according to OIML R60 standards, with dust protection. - Oven-painted steel structure, RAL 5007 blue color. - Adjustable anti-shock adjustable feet, level bubble, 2 wheels and carrying handles. - Power supply 5/15 Vdc. - 5 m shielded cable complete with connectors for connection to the indicator. - The stainless steel scales have a height of 75 mm, articulated self-centering, non-slip and anti-vibration feet, adjustable in height and structure, mechanics, AISI304 stainless steel hardware and IP68 stainless steel load cells. Order form: Code | Dimensions (LxPxH) | Load max kg | Standard division g | CE-M division g (*) 6WFP | 1260x800x85 mm | 600 | 100 | 200 15WFP | 1260x800x85 mm | 1500 | 200 | 500 30WFP | 1260x800x85 mm | 3000 | 500 | 1000 6WFPI - stainless steel | 1260x800x75 mm | 600 | 100 | 200 15WFPI - stainless steel | 1260x800x75 mm | 1500 | 200 | 500 30WFPI - stainless steel | 1260x800x75 mm | 6000 | 500 | 1000 (*) CE-M divisions obtainable only with the relative options, combined with our indicators. OPTIONAL: Weight indicators can be placed on the floor, hung on the wall or placed on the support column. - FPDFWL base weight indicator FPDFWL BASE indicators with 5-key functional waterproof keypad, 25 mm high-contrast backlit LCD display with 6 digits and icons for indicating active functions. Thanks to the ABS IP54 casing, they are easy to clean and resistant to harsh and corrosive environments. - FPDFWKPXP weight indicator - integrated printer Weight indicators with 17-key numeric-functional waterproof keypad with 25 mm backlit LCD display. with 6 high contrast digits with icons for indicating active functions. Integrated thermal printer and calendar clock. The IP65 ABS waterproof casing is easy to clean and durable, suitable for weighing in harsh and corrosive environments. - FPDFWLIP stainless steel weight indicator IP68 stainless steel weight indicator equipped with 5-key functional keyboard with 40 mm backlit color LCD display. with 6 high contrast digits and icons for indicating active functions. Ideal for applications in damp and heavy environments and in combination with stainless steel scales. With internal power supply. - FPDFWDXT weight indicator Weight indicator with large 40 mm display with high brightness red LEDs, suitable for viewing from any angle and from a great distance. Equipped with a stainless steel casing with IP68 protection rating against rain and dust, easy to clean and resistant to harsh and corrosive environments. - Support column for weight indicators - Stainless steel support column for weight indicators - CE-M approval for sales to third parties - ATEX approval for operation in potentially explosive environments (on request). In ATEX systems, for the direct weighing of light metals (aluminum, magnesium, titanium and their alloys) it is necessary that the top of the structure installed above the bars is made of stainless steel. - Brand: Ferplast - Available in painted steel or AISI 304 stainless steel - CE-M approved - Transportable, with wheels and handles - Power supply: 5/15 Vdc - Load cells: 4, OIML R60 approved - Height: 85 mm (painted), 75 mm (stainless steel) - Adjustable anti-shock feet - Level bubble - 5 m shielded cable - Optional indicators and accessories available
