Off-grid DC/AC inverter VT-2000W

pure sine waveelectronic equipmentfor home use

Product Features

• MCU microprocessor-controlled SPWM technology providing pure sine wave output
• Dynamic current loop control for stable operation under variable loads
• High compatibility with resistive, inductive, capacitive and mixed loads
• Comprehensive protections: input over-voltage/under-voltage, overload, over-temperature, short circuit and reverse connection
• LCD status display for real-time monitoring of input/output and alarms
• Suitable for household appliances, lighting, IT equipment, office devices, power tools, vehicle/on-board systems and outdoor emergency power (large motors with very high start-up current may not be supported)

Technical Parameters
Product model: VT-2000W
Brand: VOITA
Peak power: 2000 W
Continuous power: 1000 W
Input voltage: DC 12V / 24V / 48V / 60V
Output voltage: AC 110V (optional) / AC 220–240V
Output frequency: 50 Hz / 60 Hz (selectable)
Low voltage protection: 12V ≤ 9.5V ; 24V ≤ 19.5V ; 48V ≤ 39V ; 60V ≤ 53V
High voltage protection: 12V ≥ 15.8V ; 24V ≥ 30V ; 48V ≥ 60V ; 60V ≥ 72.5V
Low voltage alarm: 12V 10.2±0.5V ; 24V 21±0.5V ; 48V 43.2±0.5V ; 60V 54±0.5V
Overheat protection: >60% load threshold
Output waveform: Pure sine wave (SPWM)
Product size (example for VT-2000W): 286×103×60 mm
Weight (VT-2000W): 1.1 kg
Protection functions: short circuit, reverse connection, battery low voltage protection, low voltage alarm, high voltage protection, overload, over temperature


Model / Ratings Table
Model: VT-1000W | VT-2000W | VT-3000W | VT-4000W | VT-5000W | VT-6000W | VT-8000W
Input Voltage: 12V / 24V / 48V / 60V DC (applies to all models)
Output Voltage: 220V–240V AC (applies to all models; AC110V variants available)
Rated power: 500W | 1000W | 1500W | 2000W | 2500W | 3000W | 4000W
Peak power: 1000W | 2000W | 3000W | 4000W | 5000W | 6000W | 8000W
Frequency: 50–60 Hz (all models)
Efficiency: ≈90% (all models)
Size (per model): 210×103×60 mm | 286×103×60 mm | 288×157×75 mm | 305×150×75 mm | 315×180×140 mm | 355×180×140 mm | 460×180×140 mm
Weight (per model): 0.8 kg | 1.1 kg | 1.8 kg | 2.2 kg | 4.3 kg | 4.7 kg | 6.2 kg


Additional Size & Weight entries
VT-1000W: 210×103×60 mm / 0.8 kg
VT-2000W: 286×103×60 mm / 1.1 kg
VT-3000W: 288×140×75 mm / 1.8 kg
VT-4000W: 305×150×75 mm / 2.2 kg
VT-5000W: 315×180×140 mm / 4.3 kg
VT-6000W: 355×180×140 mm / 4.7 kg
VT-8000W: 460×180×140 mm / 6.2 kg


Warranty
2-year warranty


Specifications

• Brand: VOITA
• Commercial range: VT series
• Input voltage range: 12V / 24V / 48V / 60V DC
• Output voltage: 220V–240V AC (AC110V variants available)
• Output waveform: Pure sine wave (SPWM)
• Frequency: 50–60 Hz
• Efficiency: approx. 90%
• Rated & peak power: see model table (examples: VT-2000W — continuous 1000W, peak 2000W)
• Control & display: MCU microprocessor, LCD status display
• Protections: input over-voltage, under-voltage, overload, over-temperature, short circuit, reverse connection, battery low/high voltage alarm
• Typical applications: household appliances, lighting, IT/electronics, office equipment, power tools, vehicle/on-board systems, outdoor emergency power supply
