Forward travel vibratory plate LF 50 L

compactinggasoline engine

Product description
LF 50 L is a forward (walking) plate compactor designed for fast, efficient compaction of thin to medium layers of granular soils. The plate’s unique shape and optimized operating speed enable high production rates. The exclusive patented low‑vibration handle reduces operator exposure and the foldable handle and compact footprint simplify transport and storage.

Key specifications

• Plate width: 320 mm
• Operating weight: 55.8 kg (variant listed: 52 kg)
• Centrifugal force: 8.4 kN
• Power source: Petrol (example engine: Honda GXR120 / GX160)

Benefits / Features

• Reduced vibration exposure: Patented low‑vibration handle lowers vibration levels below 2 m/s² to support longer operating periods within regulatory limits.
• Easy transport and handling: Foldable handle, lifting eye and optional wheel kit ease movement on site and between jobs.
• Paving protection: Optional block paving kit attaches quickly to protect blocks from scratches and cracking.
• Compact storage: Handle folds completely to reduce storage footprint.

Additional product information

• Product type: Forward plate compactor
• Typical applications: Road repair, paving beds, utility trenches, landscaping
• Article number (example): 967 85 47‑04

Technical specifications

• Plate width: 320 mm
• Weight (complete product): 55.8 kg
• Centrifugal force: 8.4 kN
• Power source: Petrol (engine examples: Honda GXR120 / GX160)
• Anti‑vibration system: Patented low‑vibration handle (<2 m/s²)
• Transport features: Foldable handle, lifting eye, optional wheel kit
• Optional accessories: Block paving kit, wheel kit
