PROFIBUS USB converter 20218

built-infor LCD module

Overview
The USB-S7 Adapter MPI, DP, PPI is a USB interface that converts USB to MPI/PPI or DP-Bus for programming software and HMIs. It includes a 1.2 m MPI connecting cable that can be plugged directly into the CPU programming socket or into any node on the MPI network. The integrated LCD displays the transmission rate and the MPI/DP address. The housing features a Type B USB socket and the adapter is supplied with a USB cable for connection to the PC. The adapter is bus-powered via the PC USB and can be used at any node in the MPI bus. Compatible with S7-200, S7-300 and S7-400 controllers.

Key features

• Supports MPI, DP and PPI protocols
• 1.2 m MPI connecting cable for direct CPU or node connection
• LCD display showing transmission rate and MPI/DP address
• Type B USB socket integrated in the housing
• Supplied USB cable for PC connection
• Bus-powered from PC USB port
• Usable at any node in the MPI bus

Technical specifications

• Article number: 20218
• Model: USB-S7-Adapter (cd)
• Interface: USB to MPI/PPI or DP-Bus
• Supported protocols: MPI, DP, PPI
• MPI connecting cable length: 1.2 m
• Display: LCD (transmission rate and MPI/DP address)
• USB socket type: Type B (integrated in housing)
• Power supply: via PC USB (bus-powered)
• Installation: Plug into CPU programming socket or any node in MPI network
• Compatibility: S7-200, S7-300, S7-400
