Communication gateway ITR830-0016

industrialKNXfor condition monitoring

ITR830-0016 is an air conditioner gateway used for monitoring and controlling all the functioning parameters of Toshiba air conditioners via the KNX bus line. Bosch VRF AC - KNX Gateway is compatible with models in VRF types categorized on the compatibility list published by Interra. Bosch VRF AC - KNX Gateway has an easy installation feature and can be installed inside the own AC indoor unit or in a proper location away from the air conditioner, it connects one side directly to the electronic circuit of the AC indoor unit and on the other side directly to the KNX bus. Main Functions: • Includes 4 logical advanced parameters, each logical parameter has up to 4 inputs and can be configured as AND, OR & XOR. • Includes 8 advanced converter parameters, each converter has four operations math calculations according to the input type. • Logic and converter parameters can be used for energy savings, configurable scenes, temperature limits, etc. • The Toshiba air conditioner unit provides error notifications for errors that may occur in exceptional cases.
