Welding robot extractor hood VarioHood

modular

Short description
The VarioHood modular extraction hood captures welding fumes and dust directly at the source for welding robots and industrial process stations. The modular, plug‑together design allows multiple size configurations and variable mounting options.

Applications

• Robot extraction
• Process extraction
• Supplement to point extraction

Highlights
The VarioHood is configurable in many sizes due to its modular construction. Its innovative airflow principle reduces the required volumetric flow while maintaining effective capture. Mounting options include floor stands, ceiling suspension or integration into a mobile robot portal to simplify plant layout.

Benefits

• Low required suction power thanks to the efficient airflow principle
• Flexible plant planning due to multiple mounting variants
• Reduced transport cost and easy assembly because of the plug‑together system
• Wide range of sizes through modular design
• Improved occupational health: dust is extracted directly at the point of origin
• Protection against welding spatter for personnel and machines using KEMPER lamellas

Available dimensions (examples)

• 1.350 x 1.350 mm
• 1.350 x 1.800 mm
• 1.350 x 2.250 mm
• 1.350 x 2.700 mm
• 1.800 x 1.800 mm
• 1.800 x 2.250 mm
• 1.800 x 2.700 mm
• 900 x 1.350 mm
• 900 x 1.800 mm
• 900 x 2.250 mm
• 900 x 2.700 mm

Technical data (excerpt)
Weight: 66 kg
Depth: 1800 mm
Width: 900 mm
Suction capacity: 1300 m³/h
Article number / SKU: 2320402

Characteristics / technical specifications

• Modular, plug‑together system for multiple sizes
• Mounting variants: floor stands, ceiling suspension, integration into robot portal
• Innovative airflow principle for reduced volumetric flow requirements
• Easy transport and assembly
• Protection against welding spatter with KEMPER lamellas
