Fluid pumping station

Product Description
The transfer pump stations allow the pumping of resins, hardeners, and other media from 50 to 200-liter drums.

Applications
The transfer pump stations are suitable for supplying dosing systems, as dispensing stations, for transferring into smaller containers, and similar applications.

Easy Handling with Direct Withdrawal from the Delivery Container
The transfer pump stations enable material withdrawal for further processing directly from the delivery container. A drum lid with a seal protects the material from environmental influences.
A stirrer ensures that materials requiring regular stirring do not need manual intervention.

Easy Drum Change - with Pneumatic Pump Lifter
The drum change is simple, as the pump, stirrer, level sensor, and other attachments are lifted out of the drum by a pneumatic cylinder.
With a drum handling device, one person can change the drum alone.

Advantages

• Fast and clean filling of material pressure vessels, buckets, canisters, etc.
• Easy handling by one person
• Minimized material contact
• Possibility of centralized material supply

Technical Data
Pressure Ratio | 7.5:1
Maximum Pressure | 60 bar working pressure
Viscosity | up to 80,000 mPas
Flow Rate | 2.3 l per 20 double strokes
Air Consumption | 145 liters per minute
Maximum Drum Height | 860 mm

Options

• Version for bung hole drums
• Level monitoring
• Heating jacket
• Silica gel filter

Characteristics / Specifications

• Suitable for resins, hardeners, and other liquid media
• For 50 to 200-liter drums
• Available with or without stirrer
• Pneumatic pump lifter for easy drum change
• Drum lid with seal
• Optional: level sensor, heating jacket, silica gel filter
