Ball valve

manualisolationfor steam

Overview
A flanged steam-jacketed ball valve designed for control and isolation of high-temperature, viscous media that require trace heating to prevent solidification. Full bore CF8M stainless steel body with carbon-filled RTFE seats, suitable for steam-jacketed service and continuous operation up to +200°C.

Specifications
Design: Flanged steam jacketed
Port: Full bore
Sizes: 1/2" to 4"
Rating: ANSI Class 150/300
Body: CF8M (stainless steel)
Seats: Carbon-filled RTFE
Face-to-Face: ANSI B16.10
Temperature range: -20°C to +200°C

Features

• Full port
• Steam-jacketed body for trace heating
• Carbon-filled RTFE seats for high-temperature sealing
• CF8M stainless steel construction
• Flanged ends to ANSI standards

Applications

• High-temperature process lines
• Viscous fluids: bitumen, tar
• Resins and adhesives
• Systems requiring steam tracing to prevent solidification

Technical specifications

• Design: Flanged, steam-jacketed
• Port: Full bore
• Sizes available: 1/2" to 4"
• Pressure rating: ANSI Class 150/300
• Body material: CF8M (stainless steel)
• Seat material: Carbon-filled RTFE
• Face-to-face standard: ANSI B16.10
• Temperature range: -20°C to +200°C
