Mobile concrete mixing plant CONTIMIX 40

continuous

Mobile concrete mixing plant, purpose of this plant is to continuously mix concrete mixture in desired ratio. Main parts are hoppers for aggregate storage and concrete mixer. Concrete mixture is discharged directly from concrete mixer to belt conveyor or transport hopper. Continuous portioning of concrete mixture is performed by means of regulating rounds per minute of conveyors. Concrete mixing plant continuously mixes stone aggregate and cement in a certain ratio. The main parts of concrete mixing plant CONTIMIX 40 are the receiving basket, the concrete mixer and the cement snail transporter. Loading of stone aggregates or sand into the receiving basket is done by a loader, and from there the belt transports the aggregate into the concrete mixer where is mixed with cement. Concrete falls out directly from of the concrete mixer in the vehicle or container or belt conveyor. The amount of aggregate is regulated by electronic adjustment of the number of revolutions of the reducer. Concrete mixing plant is located on a robust collapsible chassis suitable for quick transfer from location A to location B. Main Features Mixer – ContiMix40 Mobile (Easy for transport) Easy for use and maintain. Hydraulic for door opening Mixers geometrical volume: 700l Mixing volume – output: 500l Number of aggregate belt conveyors: 2 Hoppers for two aggregate storages
