Mechanical torque limiter GDF with sprocket wheel
Add to favorites
Compare this product
Characteristics
- Operation
- mechanical, with sprocket wheel
- Torque
Min.: 5 Nm
(3.6878 ft.lb)Max.: 2,400 Nm
(1,770.1492 ft.lb)- Diameter
Min.: 10 mm
(0.39 in)Max.: 75 mm
(2.95 in)
Description
Tooth-type torque limiter with axial slippage
For dry or oil bath applications; mounted between a shaft and a pulley or a flange fixed to the toothed body (2), all perfectly aligned.
The toothed housing (3) has a groove for fitting the microswitch (9).
The calibration is adjusted by the ring nut (6), which varies the load of the springs (4) controlling the toothed housing (3).
