Pt1000 temperature sensor TM1101/51-5-1500
Pt500IP68for liquids

Pt1000 temperature sensor - TM1101/51-5-1500 - Nanjing Bocon Science & Technology Co. Ltd - Pt500 / IP68 / for liquids
Pt1000 temperature sensor - TM1101/51-5-1500 - Nanjing Bocon Science & Technology Co. Ltd - Pt500 / IP68 / for liquids
Pt1000 temperature sensor - TM1101/51-5-1500 - Nanjing Bocon Science & Technology Co. Ltd - Pt500 / IP68 / for liquids - image - 2
Add to favorites
Compare this product

Characteristics

Technology
Pt1000, Pt500
Protection level
IP68
Applications
for liquids, water, for heat meters, for ovens
Other characteristics
2-wire
Temperature

Max.: 105 °C
(221 °F)

Min.: 0 °C
(32 °F)

Probe diameter

5 mm
(0.1969 in)

Description

Swaged Probe design improved the sensor re sponse speed. Lower sensor lead error, Displayed value more closer to the true value. Mainly technical data： Follow Standard：EN1413 AND CJ128-2007 Matched pair accuracy：±0.1℃ Connecting cable：PVC，OD4.2mm，2-wire Protection tube：stainless steel 316L，Φ5 Pressure proof PN=16bar(current speed 2m/s) Connecting：Active thread（copper），G：M10×1 Single sensor meets IEC751，Tolerance Class B±（0.3+0.005|t|）℃ Each temperature sensor pair error meets the requirement of pairing error formula：Δ（ΔT）=5mk/k×ΔT+90mk ΔT; minimum measuring temperature difference.Normally 3℃，But the pairing error of each temperature sensor pair provided by BOCON is no more than 0.1℃ Resistance value at 40℃、70℃、100℃ Insulated resistance in accordance with JB/T8622-1997 (5.4) The constant insulation resistance value of platinum resistance should not be less than 100MΩ,the maximum upper limit of temperature insulation resistance 10MΩ
