Bayonet temperature probe TM1113(1)
RTDPt100Pt1000

bayonet temperature probe
bayonet temperature probe
Add to favorites
Compare this product

Go to the Nanjing Bocon Science & Technology Co. Ltd website for more information

Characteristics

Technology
Pt100, RTD, Pt1000, Pt500
Mounting
bayonet
Electrical connection
bare wires
Applications
for the plastics industry
Other characteristics
with stainless steel tube, fast-response, with spring
Temperature

Max.: 350 °C
(662 °F)

Min.: -50 °C
(-58 °F)

Probe diameter

4 mm, 6 mm, 8 mm
(0.2 in, 0.2 in, 0.3 in)

Response time

10 s

Description

Bayonet RTD temperature probes with spring TM1113(1) Technical data： Connecting cable: PVC, temperature range:-5℃~+85℃ Silicone, temperature range:-50℃~+180℃ Teflon, temperature range -50℃~+260℃ Glass Fiber, temperature range:-50℃~+350℃ Protection tube: Stainless steel 304/316, OD=4mm, 6mm,8mm Sensor element: Pt100, Pt500, Pt1000 meets IEC 751 Tolerance : Class B: △t=±(0.30 + 0.005 |t| )℃ Class A: △t=±(0.15 + 0.002 |t| )℃ Response time：t0.9 approx. 10secs, in water 0.2 m/sec, diameter 6mm
