Managed switch CSM4532

32 portslayer 2layer 3

Overview
These switches combine the configurability of a matrix switcher with the power and scalability of Ethernet to support hundreds of AV over IP endpoints. M4300 and M4500 switches include NETGEAR IGMP Plus™ to simplify system architectures at a lower cost and are pre-configured for out-of-the-box use.

Key Features

• Pre-configured for out-of-the-box use
• NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations
• Cost-effective 100G aggregation and 10G access layer for AV deployments and redundant spine & leaf topologies
• Optimized for spine-and-leaf redundant AV installations, with or without MLAG between spine switches
• High capacity for AV over IP streams — up to 320 TX / 320 RX (10 Gigabit) nodes line-rate in a redundant spine-and-leaf architecture
• IGMP Plus default on VLAN 1 and configurable on other VLANs for automatic IGMP across switches
• Two modular power supply units (APS750W) and six redundant fan trays (AFT402) pre-installed for 1+1 power and 4+2 fan redundancy

Software & Advanced Functions

• Advanced IPv4/IPv6 security including malicious code detection, DHCP Snooping, IP Source Guard, and Control Plane Policing (CoPP)
• Selectable Port-Channel / LAG (802.3ad - 802.1AX) L2/L3/L4 hashing for fault tolerance and load sharing
• Up to 64 Link Aggregation Groups (LAG/Port-Channel/LACP) with 32 ports per LAG and Multi-chassis Link Aggregation (MLAG)
• IPv4/IPv6 static and dynamic routing: IP Multinetting/CIDR, PBR, VRRPv2, OSPFv3, PIM-SM6, BGP4, VRF-Lite
• Hardware classifier-based time-aware implementation for L2 (MAC), L3 (IP) and L4 (UDP/TCP) security and QoS prioritization
• High-performance IPv4/IPv6 multicast routing with PIM-SM/PIM-SM6
• Link dependency controls to enable/disable ports based on other links' state
• Non-disruptive configuration updates for applying new config files without interrupting unchanged features
• Industry-standard management: SNMP, RMON, sFlow, LLDP, RSPAN and CLI
• Service port for out-of-band 1G Ethernet management (OOB) with CLI; RS232 straight-through RJ45 for local console

Operational & Management Highlights

• CLI-only local console; telnet port 1223 and SSH port 1234 (management via standard CLI)
• Out-of-band 1G Ethernet management port (OOB, RJ45)
• Integration with single-pane-of-glass NMS300 for centralized management
• Extensive telemetry and monitoring: SNMP, RMON, sFlow, LLDP, RSPAN

Built-in Resilience and Reliability

• Two redundant modular power supplies (APS750W) pre-installed for 1+1 power redundancy
• Six hot-swappable fan trays (AFT402) pre-installed for 4+2 fan redundancy
• Designed for high availability: nonstop forwarding failover and support for redundant spine & leaf architectures

What’s in the box

• Switch (M4500) with two power supplies (APS750W) and six fan trays (AFT402) already installed
• Console cable: DB9 female to RJ-45 serial connector
• Power cord(s)
• Two front mounting ears and screws for rack mounting
• One set of rail kits for rear rack mounting
• Installation guide

Physical Specification
Dimensions (WxDxH): 440 x 508 x 43.2 mm.
Weight: 9.78 Kg (21.54 lb).

Technical Specifications

• Denomination / Model: CSM4532
• Ports: 32 ports
• Port types: 32 x 100G/50G/40G QSFP28 (default 1×100G mode, supports 1×50G or 1×40G modes)
• 25G SFP28 Ports: N/A
• Power consumption (max): 426 Watts
• PSU and fans: 2 modular power supply units and 6 modular fan trays pre-installed
• Acoustics: 64.0 dB @ 25°C (noise reduced when both PSUs connected)
• Management: CLI-only local console; telnet port 1223 and SSH port 1234
• Management ports: 1G Ethernet service port for OOB management (RJ45); RS232 straight-through serial RJ45 for local console
• Form factor: Full-width 1U (508 mm depth) with two front mounting ears and rear rail kits
• Ordering number: CSM4532
• Model description: M4500 Managed Switch with 32×100G QSFP28 ports
• Warranty: NETGEAR limited lifetime hardware warranty (coverage and terms vary)
