1-axis scanner MiniTrak R-Frame

measurementweblaser

Overview
The MiniTrak™ R-Frame is a single-sided scanning frame designed to provide critical in-process measurements where installation space is limited. The frame supports Nordson backscatter and reflectance sensor families and reduces on-site electronics footprint by locating the intelligent iFrame module remotely.

Design and installation
The compact frame is engineered for confined process locations. Remote placement of the iFrame electronics reduces the scanner form factor and simplifies integration into existing lines with restricted access or narrow gaps.

Key features

• Single-sided scanning frame for restricted spaces
• Compact design minimizing installation footprint
• Support for Nordson backscatter and reflectance sensors
• Remote iFrame electronics module to reduce local footprint
• Suitable for integration in calendering and other tight process areas

Supported sensors

• Nordson backscatter sensor family
• Nordson reflectance sensor family
• Example: GBS - Gamma Thickness Gauge

Typical applications

• Thickness and surface measurements in rubber calendering
• In-line process monitoring where space is constrained
• Installation points requiring a reduced scanner footprint

Technical specifications

• Product type: Single-sided scanning frame (R-Frame)
• Model: MiniTrak™ R-Frame
• Sensor compatibility: Nordson backscatter & reflectance families
• Electronics: Remote iFrame module (reduces local form factor)
• Installation: Minimal space required; designed for confined process locations
