Transmission chain CL series

steeltimingfor engine

Product Description Timing silent chains for automobile engine Silent chain for engine timing is mainly used for automobile engine timing system. The chain is the key engine component with excellent performances such as high strength, durability and silencing and so on. Parameter Chain No.: CL04DF3, CL04DF10, CL05D, CL05V Pitch: 6.35 mm, 8.00 mm Chain width: 7.80 mm - 8.86 mm Pin diameter: 2.70 mm - 3.15 mm Pin length: 10.48 mm - 12.70 mm Plate depth: 7.13 mm - 9.59 mm Plate thickness: 1.00 mm - 1.30 mm Guide form: Outside Number of plate: 7(3×4) to 9(5×4) Tensile strength: 10.0/2250 kN/lbf to 16.0/3600 kN/lbf Weight per meter: 0.38 kg/m to 0.52 kg/m Technical Specifications / Features Application: Engine timing system for automobiles Features: High strength, durability, silencing Key component for engine timing
