1-axis inclinometer OIAC3
CANopenanalogMEMS

1-axis inclinometer
1-axis inclinometer
Add to favorites
Compare this product


Characteristics

Number of axes
1-axis
Output
CANopen, analog
Technology
MEMS
Other characteristics
rugged, IP67, concentrated solar power
Inclination

Max.: 360 °

Min.: 0 °

Resolution

0.001 °

Description

OIAC3 1 and 2 axes Inclination Sensor CANopen Certified Interface OIAC3 is a 1D or 2D inclination sensor based on MEMS (Micro Electro Mechanical Systems) technology. The device senses tilt angles up to ±60 de-grees in the pitch and roll axis and 360 degrees in a sin-gle-axis measure. OIAC3 is compact and rugged. The metal anodized en-closure makes it robust to external shocks and vibrations, dust and harsh conditions. The MEMS signals are inter-nally filtered by an analog second order low-pass filter with cut-off frequency of 20Hz (hardware filter) and an user programmable digital filter (moving average). The two filters produce an enhanced noise rejection, increas-ing the measure stability. The output interface is CAN-OPEN certified, fully com-pliant with DS 301 DSP 410. OIAC3 is programmable via CAN frames without additional tools. OIAC3-A000-M is highly accurate (+/-0.05°) and can be set in the preferred mode of measurement (1 or 2 axes). OIAC3-1360-M and OIAC3-2060-M are respectively 1-axis and 2-axes inclinometers with medium accuracy (+/-0.2°). Single channel or redundant versions are available. OIAC3 is guaranteed in the full industrial temperature range [-40;+85]°C. A compensation in the temperature range is available in order to reduce the thermal drift by a factor of 4. Such compensation is available for OIAC3-A000 and it is suggested whenever a higher total accura-cy is required (e.g. concentrated solar power). Applications  Construction equipment  Aerial platforms  Concentrated Solar Power plants  Agricultural and forestry machines  Mining and well drilling equipments Features  High resolution (up to 0.001 deg)  High accuracy device
