Motorized goniometer 202625

• Self-collimation system ZBL ensuring a contrasted self-collimation on any flat surface • Slot with symmetric opening by vernier at 1/100th of a mm • Microlithographed micrometer ensuring very good precision with LED lighting Dive into the heart of the study of chromatographic dispersion systems with our spectrogoniometer. This device, designed for Higher Education needs, is intended to offer precision of one arc minute and excellent robustness. The device has 3 constituent arms: - a self-collimating sighting telescope with adjustable lighting, - an adjustable symmetric collimated slit by micrometric vernier, - an auxiliary projection collimator allowing to display a graduation in the background of the spectrum. It also includes numerous accessories (prisms, gratings, supports...) Take advantage of its unique benefits for high-quality scientific experiments! Plate Diameter: 220 mm Axis Height: 380 mm Mass: 10 kg Material: stainless steel, aluminum, brass Reading Precision: 1 arc minute Autocollimating Eyepiece: - illumination with high brightness white LED, 2.1 mm jack output - adjustable and orientable ZBL cross-type reticle to prevent stray light reflections - focal adjustment by concentric adjustment - horizontal adjustment Slit Collimator: - adjustable and orientable symmetrical slit - slit adjustment with micrometric vernier to 1/100th - focal adjustment by concentric adjustment - horizontal adjustment Auxiliary Eyepiece: - illumination with high brightness white LED with jack output - 1/20th micro-lithography micrometric reticle - horizontal adjustment
