Avalanche photodiode array XSJ-10-APD3A-200X-K10

chip

Avalanche Photodiode Chip (APD Chip) is a kind of active device that provides a built-in gain and amplifies the photocurrent. This 1X10 Array product features is anode on top and cathode on back, with top-illuminated active area of Φ200μm for easy optical assembly; High responsivity, High Multiplication Factor and low dark current. The high-performance 1.25Gbps APD Chip Package for Single tube TO-CAN can improve the sensitivity of optical receiver, applications that OTDR. 1. Φ200μm active area, 1X10 Array. 2. Die pitch: 340μm. 3. Anode on top and cathode on back. 4. Low dark current. 5. Excellent responsivity and high gain. 6. Data rate up to 1.25Gbps. 7. Excellent reliability: All chips have passed the qualification requirements as specified by Telcordia -GR-468-CORE. 8. 100% testing and inspection. Applications 1. Optical Time Domain Reflectometer(OTDR). 2. Laser range finder/Distance measurement. 3. Spatial light transmission. 4. Low-light-level detection. 5. Laser alarming and LIDAR.
