Automatic filling machine

for powdersfor the food industryfor the chemical industry

Product overview
The twin-head auger powder filling machine is an automated system for medium-to-high output production requiring high-precision quantitative dosing. It features two independent filling stations driven by servo-controlled augers; the two nozzles can operate simultaneously or independently to increase throughput. The machine handles a wide range of powdered materials such as milk powder, protein powders, pharmaceutical powders, spices, seasonings and chemical powders. Compact footprint and intuitive controls make it suitable for medium-to-large production lines.

Key features

• Dual-station independent servo control: each filling head has its own servo motor for separate fill settings and synchronous or alternating operation, delivering approximately 1.6–2× the output of single-head models.
• High-precision auger dosing: servo control of auger speed and rotation cycles ensures stable accuracy of ±1%–2% for quantitative filling.
• PLC with touchscreen HMI: large display, multiple recipe storage and one-touch parameter recall to simplify changeovers and reduce operator training.
• Modular maintenance design: independent twin-head structure allows disassembly and service of one head without stopping the other.
• Optional submerged nozzles: extend into containers to reduce dust emission for fine or easily dispersed powders.
• Optional hopper agitator and dust-extraction ports: slow-speed agitator prevents bridging; dedicated ports enable connection to external dust collectors to meet GMP requirements.
• All-contact stainless steel construction: contact parts in 304 or 316L stainless steel for food and pharmaceutical hygiene, corrosion resistance and easy cleaning.

Application scenarios

• Health & nutraceutical products (protein, probiotic, collagen powders)
• Food industry (milk powder, coffee, spices, seasoning powders, flour)
• Pharmaceuticals (medicinal powders, herbal powders, veterinary powders)
• Chemicals (fine chemical powders, pigments, additives)
• Household products (detergent powders, cleaning powders)

Specifications / Technical data

• Configuration: twin-head (dual-station) auger filling machine with two independent nozzles.
• Drive & dosing: independent servo motor control per head; auger (screw) dosing system.
• Accuracy: typically ±1%–2% under servo-controlled auger dosing.
• Throughput: approximately 1.6–2× the output of comparable single-head models.
• Control system: PLC with large HMI touchscreen; multi-recipe storage and one-touch recall.
• Materials in contact: 304 or 316L stainless steel (food/pharma grade).
• Optional equipment: submerged nozzles, hopper agitator (slow-speed), dust extraction ports for external collectors.
• Maintenance: modular twin-head design for independent disassembly and servicing.
• Suitable for: milk powder, protein powders, pharmaceutical powders, spices and seasonings, fine chemicals and detergent powders.
