Hydraulic radial piston pump axial pistonelectricfor industrial applications
Add to favorites
Compare this product
Characteristics
- Type
- axial piston, radial piston
- Operation
- electric
- Applications
- for industrial applications
- Other characteristics
- oil, adjustable
- Pressure
Min.: 400 bar
(5,801.5 psi)Max.: 700 bar
(10,152.6 psi)- Flow rate
Min.: 1.5 l/min
(0.4 us gal/min)Max.: 11.6 l/min
(3.06 us gal/min)- Weight
Min.: 110 kg
(242.51 lb)Max.: 210 kg
(462.97 lb)- Power
Min.: 3 kW
(4.08 hp)Max.: 7.5 kW
(10.2 hp)
Description
• Electric motor EUROPEAN STANDARDS, 240/415V-50Hz three-phase, 1500tr/min, IP55 class F
• Radial or axial piston pump
• Tank 40 and 80 liters (delivered with oil) with :
– 20 µ return filter
– 15 µ filtered air breather
– Oil drain plug
– Oil level gauge
• Adjustable pressure relief valve
• 240V single-phase motor
• Switch box with electrical shut-down feature to prevent from unintentional restarting of motor following an electrical service interruption
• Protection frame
• Oil retaining tray
