Magnetic proximity sensor BM

cylindricalbare wiresstainless steel

Description
The Soldo Controls BM series proximity switches provide a compact solution for remote valve position feedback in linear and rotary valves and for general-purpose feedback in harsh environments such as hazardous areas and explosive atmospheres with Exd or Exia protection methods. Subsea variants are available on request and have been tested up to 300 bar.

Features

• Designed for linear and rotary valves and general-purpose applications
• Compact position indication for linear valves
• Adaptable to multiple application configurations
• AISI 316 stainless steel enclosure
• 450 mm flying leads
• Magnetic or ferrous target sensing
• Subsea version available on request; tested up to 300 bar

Technical specifications

• Model: BM
• Brand: Soldo Controls
• Applications: Remote valve position feedback for linear and rotary valves; general-purpose feedback in harsh environments
• Enclosure material: AISI 316 stainless steel
• Cable: 450 mm flying leads
• Sensing: Magnetic or ferrous target
• Protection: Suitable for hazardous areas and explosive atmospheres (Exd or Exia)
• Subsea: Available on request; tested up to 300 bar
