Wire connection system DS20-GT

Product overview
The DS20-GT is a connector designed for joining conductors to ground terminals in wire-harness assemblies. The main cross-section range is 1.0 mm² to 25 mm², with an alternate splicing note of 1.5 mm² to 25 mm². Its compact design reduces installation space and material usage while supporting improved electrical performance.

Key benefits

• Cross-section range: 1.0 mm² to 25 mm²
• Operating frequency: 20 kHz
• Insulation crimp; terminal tool included

Applications
Intended for ground terminals in wire harnesses and grounding contacts. Typical use cases include automotive and industrial harness assemblies where reliable ground connections and space savings are required.

Technical specifications

• Model: DS20-GT
• Main cross-section range: 1.0 mm² to 25 mm² (alternate splicing range on page: 1.5 mm² to 25 mm²)
• Operating frequency: 20 kHz
• Crimp type: Insulation crimp
• Includes: terminal tool
• Primary application: ground terminals in wire harnesses
