Centrifugal pump SUD100DG-B38CS
slurrywith electric motorindustrial

Centrifugal pump - SUD100DG-B38CS - Shijiazhuang Sunbo Pump Co., Ltd - slurry / with electric motor / industrial
Centrifugal pump - SUD100DG-B38CS - Shijiazhuang Sunbo Pump Co., Ltd - slurry / with electric motor / industrial
Centrifugal pump - SUD100DG-B38CS - Shijiazhuang Sunbo Pump Co., Ltd - slurry / with electric motor / industrial - image - 2
Add to favorites
Compare this product

Characteristics

Technology
centrifugal
Fluid
slurry
Operation
with electric motor
Domain
industrial
Applications
dewatering, cleaning, booster, transfer, discharge, feed, mixing
Other characteristics
horizontal mount, two-stage, high-efficiency
Flow

Min.: 40 m³/h
(1,412.58667 ft³/h)

Max.: 171 m³/h
(6,038.80801 ft³/h)

105 m³/h
(3,708.04001 ft³/h)

Pressure

Min.: 1.85 bar
(26.832 psi)

Max.: 9.41 bar
(136.481 psi)

5.63 bar
(81.656 psi)

Head

Min.: 18.5 m
(60'08" )

Max.: 94.1 m
(308'08" )

56.3 m
(184'08" )

Power

Min.: 30 kW
(40.79 hp)

Max.: 90 kW
(122.37 hp)

60 kW
(81.58 hp)

Description

The pumps are pumps are designed for the continuous pumping of highly abrasive, high density slurries with minimal maintenance requirements, the horizontal centrifugal pumps will maintain high efficiencies over the wear life of its components. The rubber and metal lined pumps feature casings which are radially split into two halves. Minimum casing bolts reduce maintenance and minimise downtime. The centrifugal slurry pumps used as, Booster pump, De-Watering Screen Pump, Tailings Pump, Metboom Pump, Feedprep Pump, Scavenger Feed Pump, Re-Cleaner Pump, Ball mill discharge Pump, Ruffer Feed Pump, Transfer to feedprep Pump, Metboom Return Pump, Thickner Underflow Pump, Thickner Tailings Pump, Thickner Underflow Pump, Rinse Pump, Dilute Pump, Re-Cleaner Pump, Rougher Feed Pump, Tailings booster Pump, Mill slurry Pump, Mill feed water Pump, Disc filter basin flushing Pump, Mixing tank slurry Pump, Gas cleaning slurry Pump, Windbox slurry Pump, Pellet hand scrubber slurry pump, Process recycle Pump, Scrubber slurry Pump, Prop pellets undersize Pump, Screen feeder Pump, Furn disch scrubber slurry Pump, Cosmetic recycle water Pump, Backwash Pump, Venturi scrubber slurry pump, Clarifier underflow pump, Pipeline transfer pump etc.

Catalogs

No catalogs are available for this product.

See all of Shijiazhuang Sunbo Pump Co., Ltd‘s catalogs
