Industrial fan CLD - AERIS high-performancecentrifugaldust control
Add to favorites
Compare this product
Characteristics
- Type
- high-performance
- Configuration
- centrifugal
- Function
- extraction, ventilation, dust control
- Drive mechanism
- electrically-powered
- Material
- steel
- Applications
- industrial
- Air flow
Max.: 80,000 m³/h
(2,825,173.338 ft³/h)Min.: 1,225 m³/h
(43,260.467 ft³/h)
Description
MEDIUM PRESSURE CENTRIFUGAL FAN
INDUSTRIAL EXECUTION: SYSTEM 4 - DIRECT DRIVE ARRANGEMENTMEDIUMPRESSURE CENTRIFUGAL FAN
INDUSTRIAL EXECUTION: SYSTEM 4 - DIRECT DRIVE ARRANGEMENT
The AERIS-P series by SDT Air has been specifically designed for industrial applications requiring high airflow rates under medium-pressure conditions.
Its System 4 configuration—with the impeller directly mounted on the motor shaft and the motor supported on a rigid base frame—ensures permanent alignment, maximum power transmission, and a significant reduction in maintenance requirements.
ARCHITECTURE, INTEGRITY AND OPERATING CONDITIONS
Design Evolution and Materials
All ferrous metal components of the fan are manufactured from carbon steel, ensuringstructural robustness and long service life in industrial environments.
The casing is adapted to the equipment size to optimize strength and durability:
- Sizes up to 630: high-precision lock-seam construction
- Sizes from 630 upwards: continuously welded construction for maximum structural rigidity
Dynamic Stability
- Incorporation of a front support foot to minimize vibrations
- Optional up to size 500
- Standard from size 560 onwards
Backward-Curved Impeller
- Backward-curved blade impeller with self-cleaning profile
- Statically and dynamically balanced
- Quiet and efficient operation
Installation Versatility
- Field-adjustable orientation up to size 630
- For sizes 710 to 1000, orientation is factory-defined to ensure assembly integrity
Operating Conditions – Thermal Execution
- Standard execution: suitable for continuous operation with air up to 130 °C
- High-temperature executions: achieved through specific configurations including cooling impellers, material selection, and design solutions adapted to thermal expansion
These executions allow continuous operation up to 250 °C while maintaining the structural reliability of the equipment.
MOTORISATION AND EFFICIENCYMOTORISATION AND EFFICIENCY
TEFC Motors
Equipped with Totally Enclosed Fan Cooled (TEFC) motors, designed for reliable
operation in demanding industrial environments.
ErP Compliance
- IE3 (Premium Efficiency): standard from 0.75 kW to 55 kW
- IE4 (Super Premium Efficiency): from 75 kW onwards
- IE2 (High Efficiency): for ratings below 0.75 kW
STANDARD FINISHSTANDARD FINISH
- Standard industrial coating, suitable for applications in non-aggressive industrial
environments
INDUSTRIAL EXECUTION: SYSTEM 4 - DIRECT DRIVE ARRANGEMENTMEDIUMPRESSURE CENTRIFUGAL FAN
INDUSTRIAL EXECUTION: SYSTEM 4 - DIRECT DRIVE ARRANGEMENT
The AERIS-P series by SDT Air has been specifically designed for industrial applications requiring high airflow rates under medium-pressure conditions.
Its System 4 configuration—with the impeller directly mounted on the motor shaft and the motor supported on a rigid base frame—ensures permanent alignment, maximum power transmission, and a significant reduction in maintenance requirements.
ARCHITECTURE, INTEGRITY AND OPERATING CONDITIONS
Design Evolution and Materials
All ferrous metal components of the fan are manufactured from carbon steel, ensuringstructural robustness and long service life in industrial environments.
The casing is adapted to the equipment size to optimize strength and durability:
- Sizes up to 630: high-precision lock-seam construction
- Sizes from 630 upwards: continuously welded construction for maximum structural rigidity
Dynamic Stability
- Incorporation of a front support foot to minimize vibrations
- Optional up to size 500
- Standard from size 560 onwards
Backward-Curved Impeller
- Backward-curved blade impeller with self-cleaning profile
- Statically and dynamically balanced
- Quiet and efficient operation
Installation Versatility
- Field-adjustable orientation up to size 630
- For sizes 710 to 1000, orientation is factory-defined to ensure assembly integrity
Operating Conditions – Thermal Execution
- Standard execution: suitable for continuous operation with air up to 130 °C
- High-temperature executions: achieved through specific configurations including cooling impellers, material selection, and design solutions adapted to thermal expansion
These executions allow continuous operation up to 250 °C while maintaining the structural reliability of the equipment.
MOTORISATION AND EFFICIENCYMOTORISATION AND EFFICIENCY
TEFC Motors
Equipped with Totally Enclosed Fan Cooled (TEFC) motors, designed for reliable
operation in demanding industrial environments.
ErP Compliance
- IE3 (Premium Efficiency): standard from 0.75 kW to 55 kW
- IE4 (Super Premium Efficiency): from 75 kW onwards
- IE2 (High Efficiency): for ratings below 0.75 kW
STANDARD FINISHSTANDARD FINISH
- Standard industrial coating, suitable for applications in non-aggressive industrial
environments
