Transport trolley CTS04 series

laboratorystoragehandling

Overview
This CTS04 series medical gas cylinder trolley is designed for safe vertical movement and secure storage of flat‑bottom medical gas cylinders (including oxygen). Cylinders are retained at all times by neoprene straps and the mirror‑polished 304 stainless finish facilitates cleaning and disinfection for clinical environments. Suitable for hospital wards, clinics and laboratories.

Key features

• Stainless steel construction: 304‑grade stainless steel tubing with TIG‑brushed weld finish and mirror polish for a smooth, paint‑free surface that is easy to clean.
• Gas cylinder size variants: CTS04-A (large) and CTS04-B (small) to accommodate different cylinder diameters and heights.
• Elasticated rubber tyres: Plastic‑centred 160 mm wheels fitted with elasticated rubber tyres and precision bearings for smooth, low‑effort movement. ATEX/UKEX variants supplied with anti‑static tyres and earthing chains.
• Retaining straps: Neoprene securing straps, 5 mm thick, multiple securing positions; quiet and easy to use in medical areas.

Specification
CTS04-A — Medical Gas Cylinder Trolley (Large)
Rated capacity: 80 kg
Cylinder heights: 500 mm to 1350 mm
Cylinder diameters: 100 mm to 200 mm
Securing straps: Three neoprene securing straps, 5 mm thick
Manual force required to operate: Less than 10 kg
Wheel specification: Plastic‑centred 160 mm wheels with elasticated rubber tyres and precision bearings
Trolley dimensions: 1280 mm high, 450 mm wide, 395 mm deep
Compliance: CE / UKCA

CTS04-A-Ex — ATEX / UKEX Medical Gas Cylinder Trolley (Large)
Rated capacity: 80 kg
Cylinder heights: 500 mm to 1350 mm
Cylinder diameters: 100 mm to 200 mm
Securing straps: Three neoprene securing straps, 5 mm thick
Manual force required to operate: Less than 10 kg
Wheel specification: Plastic‑centred 160 mm wheels with anti‑static tyres and precision bearings
Trolley dimensions: 1280 mm high, 450 mm wide, 395 mm deep
Compliance: CE / UKCA and ATEX / UKEX (zones 1, 2, 21, 22)

CTS04-B — Medical Gas Cylinder Trolley (Small)
Rated capacity: 60 kg
Cylinder heights: 500 mm to 950 mm
Cylinder diameters: 100 mm to 150 mm
Securing straps: Two neoprene securing straps, 5 mm thick; strap positions from floor: 230 mm and 490 mm
Manual force required to operate: Less than 10 kg
Wheel specification: Plastic‑centred 160 mm wheels with elasticated rubber tyres and precision bearings
Trolley dimensions: 1080 mm high, 405 mm wide, 340 mm deep
Compliance: CE / UKCA

CTS04-B-Ex — ATEX / UKEX Medical Gas Cylinder Trolley (Small)
Rated capacity: 60 kg
Cylinder heights: 500 mm to 950 mm
Cylinder diameters: 100 mm to 150 mm
Securing straps: Two neoprene securing straps, 5 mm thick; strap positions from floor: 230 mm and 490 mm
Manual force required to operate: Less than 10 kg
Wheel specification: Plastic‑centred 160 mm wheels with anti‑static tyres and precision bearings
Trolley dimensions: 1080 mm high, 405 mm wide, 340 mm deep
Compliance: CE / UKCA and ATEX / UKEX (zones 1, 2, 21, 22)

Technical specifications

• Material: 304‑grade stainless steel, mirror‑polished tubing, TIG‑brushed weld finish
• Models / series: CTS04 series (CTS04-A large, CTS04-B small)
• Rated capacity: CTS04-A = 80 kg; CTS04-B = 60 kg
• Cylinder heights: CTS04-A 500–1350 mm; CTS04-B 500–950 mm
• Cylinder diameters: CTS04-A 100–200 mm; CTS04-B 100–150 mm
• Securing straps: Neoprene, 5 mm thick (three straps on CTS04-A; two straps on CTS04-B)
• Wheel spec: Plastic‑centred 160 mm wheels with elasticated rubber tyres and precision bearings (anti‑static tyres available for ATEX/UKEX variants)
• Manual operating force: Less than 10 kg
• Trolley dimensions: CTS04-A 1280 × 450 × 395 mm (H × W × D); CTS04-B 1080 × 405 × 340 mm (H × W × D)
• Compliance: CE / UKCA; optional ATEX / UKEX certification for zones 1, 2, 21, 22
