Plastic dolly DDL01

metalfor drumsfor transport

Product overview
The oil drum dolly is a compact, low-profile transport platform designed for safe handling and storage of drums. It features a central X-frame with an outer steel ring and is supplied with four braked swivel castors to enable easy manoeuvring and secure parking in storage areas. A stainless-steel construction is available for food, pharmaceutical and GMP/clean-room environments.

Key product features

• High-quality wheels and bearings: aluminium-centred wheels with polyurethane tyres and precision bearings to minimise rolling resistance; all four castors fitted with foot-operated park brakes as standard.
• Fabrication and weld control: manufactured by qualified welders with weld inspection by a second operator to ensure conformity to industrial fabrication standards.
• Safe drum loading: compatible with drum tippers and drum-lifting trolleys for controlled placement of drums onto the dolly; intended for use on flat, level surfaces to prevent accidental roll-away.

Specification

• Rated capacity: 350 kg
• Drum compatibility: steel and plastic drums 160–220 L (450–600 mm diameter)
• Manual force required to operate: < 20 kg
• Construction: mild steel, grit blasted
• Surface finish: primer and polyester powder coat
• Unit colour: RAL 5010 (blue)
• Wheel arrangement: four braked swivel castors
• Wheel specification: aluminium-centred wheels with polyurethane tyres and precision bearings
• Compliance: CE / UKCA

Optional features

• Stainless-steel model: available for clean-room and GMP areas.
• ATEX certification: fully certified ATEX version available for gas and dust Zones 1, 2, 21 and 22 (optional).

Technical specifications

• Rated capacity: 350 kg
• Drum compatibility: 160–220 L (450–600 mm diameter), steel and plastic
• Manual force required: < 20 kg
• Construction: mild steel; stainless-steel option available
• Finish: primer + polyester powder coat
• Colour: RAL 5010 (blue)
• Wheels: aluminium-centred, polyurethane tyres, precision bearings
• Castors: 4 braked swivel castors
• Compliance: CE / UKCA; ATEX optional
