Die sinking EDM HPS-540
high-accuracyhigh-speedflexible

Die sinking EDM - HPS-540 - SXKH GLOBAL - high-accuracy / high-speed / flexible
Die sinking EDM - HPS-540 - SXKH GLOBAL - high-accuracy / high-speed / flexible
Die sinking EDM - HPS-540 - SXKH GLOBAL - high-accuracy / high-speed / flexible - image - 2
Die sinking EDM - HPS-540 - SXKH GLOBAL - high-accuracy / high-speed / flexible - image - 3
Die sinking EDM - HPS-540 - SXKH GLOBAL - high-accuracy / high-speed / flexible - image - 4
Add to favorites
Compare this product
Go to the SXKH GLOBAL website for more information

Characteristics

Type
die sinking
Other characteristics
high-accuracy, high-speed, flexible, for mold manufacturing
X travel

500 mm
(19.69 in)

Y travel

400 mm
(15.75 in)

Z travel

300 mm
(11.81 in)

Description

MODEL:HPS-540
X/Y1Z-axis working stroke 500 /400 /300mm
Working oil tank volume (LxWxH) 1300x920x450mm
Table specifications (LxW) 800x500mm
Distance from electrode head to table 300-600mm
Max. electrode load 100KG
Max. worktable load capacity 1800KG
Net machine weight(including oil tank) 3000KG
Size (LxWxH) 1640x2200x2250mm
Oil tank size (LxWxH) 1300x920x450mm
