Sinker electrical discharge machine HPX-600

high-accuracyhigh-productivityfor mold manufacturing

MODEL: HPX-600
X/Y/Z-axis working stroke 650/400/350mm
Working oil tank size(LxWxH) 1600x900x580mm
Table size (LxW) 900x500mm
High-Gloss Mirror Circuit (Best Surface Finish) 0.13Ra
Max. Machining Speed 500 mm3/min
Distance from electrode tip to table 750mm
Max. electrode load capacity 150KG
Max. worktable load capacity 2000KG
Machine weight(including oil tank) 3700KG
Machine Dimension (LxWxH) 2040x2320x2530mm
Max. machining current 50A
Positioning accuracy 5 um
Repeat positioning accuracy 2um

Machine Features:

• X, Y, and Z axis all use Taiwan grinding-grade ball screws.
• Complete peripheral facilities, such as automatic fire extinguishing devices and surface sensing devices for processing fluids, to provide a safe environment.
• The body is made of FC30 cast iron, which has undergone high-temperature annealing and natural aging treatment.
• X axis and Y axis are designed with full-enclosed reinforced slides, and X-axis rail distance is greater than Y-axis stroke, to ensure the parallelism between the entire stroke of X/ Y axis and the table.
