Sinker electrical discharge machine HPX-1200

high-accuracyhigh-productivityflexible

MODEL: HPX-1200
X/Y/Z-axis working stroke 1200/600/500mm
Working oil tank size(LxWxH) 2200x1150x570mm
Table size (LxW) 1300x800mm
High-Gloss Mirror Circuit (Best Surface Finish) 0.13Ra
Max. Machining Speed 500 mm3/min
Distance from electrode tip to table 500-950mm
Max. electrode load capacity 180KG
Max. worktable load capacity 3500KG
Machine weight(including oil tank) 6000KG
Machine Dimension (LxWxH) 2600x3065x3100mm
Max. machining current 50A
Positioning accuracy 5 um
Repeat positioning accuracy 2um

Machine Features:

• X, Y, and Z axis all use Taiwan grinding-grade ball screws.
• Complete peripheral facilities, such as automatic fire extinguishing devices and surface sensing devices for processing fluids, to provide a safe environment.
• The body is made of FC30 cast iron, which has undergone high-temperature annealing and natural aging treatment.
• X axis and Y axis are designed with full-enclosed reinforced slides, and X-axis rail distance is greater than Y-axis stroke, to ensure the parallelism between the entire stroke of X/ Y axis and the table.
