Die sinking electrical discharge machine HPX-500
high-speedprecisionhigh-productivity

Die sinking electrical discharge machine - HPX-500 - SXKH GLOBAL - high-speed / precision / high-productivity
Die sinking electrical discharge machine - HPX-500 - SXKH GLOBAL - high-speed / precision / high-productivity
Die sinking electrical discharge machine - HPX-500 - SXKH GLOBAL - high-speed / precision / high-productivity - image - 2
Add to favorites
Compare this product
Go to the SXKH GLOBAL website for more information

Characteristics

Type
die sinking
Other characteristics
CNC, precision, high-speed, high-productivity, for metalworking tools, with electrode changer, with automatic loader, low power consumption
X travel

500 mm
(19.69 in)

Y travel

400 mm
(15.75 in)

Z travel

300 mm
(11.81 in)

Description

MODEL: HPX-500
X/Y/Z-axis working stroke 500/400/300mm
Working oil tank size(LxWxH) 1300x880x540mm
Table size (LxW) 800x500mm
High-Gloss Mirror Circuit (Best Surface Finish) 0.13Ra
Max. Machining Speed 500 mm3/min
Distance from electrode tip to table 700mm
Max. electrode load capacity 120KG
Max. worktable load capacity 1800KG
Machine weight(including oil tank) 3000KG
Machine Dimension (LxWxH) 2300x2770x2650mm
Max. machining current 50A
Positioning accuracy 5 um
Repeat positioning accuracy 2um

Machine Features:

  • X, Y, and Z axis all use Taiwan grinding-grade ball screws.
  • Complete peripheral facilities, such as automatic fire extinguishing devices and surface sensing devices for processing fluids, to provide a safe environment.
  • The body is made of FC30 cast iron, which has undergone high-temperature annealing and natural aging treatment.
  • X axis and Y axis are designed with full-enclosed reinforced slides, and X-axis rail distance is greater than Y-axis stroke, to ensure the parallelism between the entire stroke of X/ Y axis and the table.
