Thyristors power controller TS3

three-phaseDIN rail

The TS3 three-phase power thyristor controller is used to control the load or power of industrial load applications (e.g. fans, pumps, lamps, heating coils, industrial ovens). Its solid and compact design permit seamless installation and a wear-free control with a high degree of efficiency. • Application/type : Power thyristors • Configuration : DIP switches • Output voltage : reference voltage for potentiometer: 10 V = • Output switch contact : signal contact at 100% Ua, signal contact in case of fault state, changeover contacts, 2A for 230 V ~, output for ohmic and inductive loads, 10 kW (400 V ~ / 15 A), 16 kW (400 V ~ / 25 A), 23 kW (400 V ~ / 35 A), 33 kW (400 V ~ / 50 A) • Input : input for potentiometer 2,5..10 kΩ, PWM input 5 V / 5..10 kHz, input for PTC according to DIN 44081, input for reset, electrical activation via setpoint signal 0..10 V = or 0..20 mA, optionally configurable • Operating range temperature (°C) : 0..+50 • Operating range humidity : max. 95% rH non-condensing • Power supply : L1, L2, L3, N: 400 V ~ 45..65 Hz, self-synchronizing • Power consumption : typ. 40 W, typ. 67 W, typ. 94 W, typ. 135 W • Display : 4 LEDs showing status of the device • Enclosure : aluminium • Protection (IP) : IP40, according to EN 60529 • Connection : terminal block • Mounting : 4 mounting holes Ø=8 mm for mounting on galvanized mounting plates (control cabinet) • Device length (mm) : 139 • Device width (mm) : 200 • Device height (mm) : 140
