Resin 3D printer FL660

industrialprototypingfor model making

Product Overview:
Large-format stereolithography (SLA) 3D printer using a 355 nm frequency‑tripled solid‑state laser (Nd:YVO4) with dynamic, variable beam focus and beam size from 0.07–0.70 mm. Reproduces surface and side details down to 0.06 mm. Configurable forming format, replaceable or fixed resin vat, closed‑loop systems control and EPM remote monitoring via UnionTech™ RSCON. CE certified.

Recommended Applications:

• Mass production of wooden molds
• Rapid tooling and short-run production
• R&D and prototyping of samples
• Try-on and fit iterations for new products

ONE PRINTER, MULTIPLE INDUSTRIES:

• Wood mold manufacturing
• Surface texture and pattern replication
• Creative and industrial design
• Footwear and consumer goods prototyping
• Processing of soft materials

FL660 Technical Data:
Build Volume: 600 × 600 × 400 mm (23.6 × 23.6 × 15.75 in)
Accuracy: Dimension < 100 mm: ±0.1 mm; Dimension ≥ 100 mm: ±0.1% × Dimension
Layer Thickness: 0.05–0.25 mm
Laser: 355 nm, frequency‑tripled solid‑state (Nd:YVO4)
Beam Focus: Dynamic & Variable
Beam Size: 0.07–0.70 mm
Scanning Speed: 8–14 m/s
Control Software: UnionTech™ RSCON
Data Interface: .stl
Network: Ethernet, IEEE802.3, TCP/IP
Rated Power: 2.6 kVA
Systems Control: Closed‑loop
Operating Temperature: 22–26 °C (72–79 °F)
Relative Humidity: < 40%
Resin Vat: Replaceable / Fixed
Machine Dimensions: 1430 × 1310 × 2221 mm (56.30 × 51.58 × 87.44 in)
Machine Weight: 850 kg

Specifications / Technical Features:

• Build Volume: 600 × 600 × 400 mm (23.6 × 23.6 × 15.75 in)
• Accuracy: <100 mm: ±0.1 mm; ≥100 mm: ±0.1% × Dimension
• Layer Thickness: 0.05–0.25 mm
• Laser: 355 nm, frequency‑tripled solid‑state (Nd:YVO4)
• Beam Focus: Dynamic & Variable
• Beam Size: 0.07–0.70 mm
• Scanning Speed: 8–14 m/s
• Control Software: UnionTech™ RSCON
• Data Interface: .stl
• Network: Ethernet, IEEE802.3, TCP/IP
• Rated Power: 2.6 kVA
• Systems Control: Closed‑loop
• Operating Temperature Range: 22–26 °C (72–79 °F)
• Relative Humidity: < 40%
• Resin Vat: Replaceable / Fixed
• Machine Dimensions: 1430 × 1310 × 2221 mm
• Machine Weight: 850 kg
