Hydraulic fitting Sanpress Inox LF

cutting ringseatstainless steel

Flow-​optimised press connector system with press connectors made of stainless steel 1.4401 and pipes from stainless steel 1.4401 and 1.4521. Free of paint-​wetting impairment substances (PWIS-​free) such as silicone, grease or oil. Especially suitable for the use of piping installations in paint shops. Press connectors for protecting the sealing element equipped with cylindrical pipe guide. Press connectors from d64.0 with stainless steel cutting ring to ensure the mechanical strength of the connection. For protection pipes are equipped with pipe plugs. The pressing force is located before and behind the sealing element seat. Suitable for concealed and pre-​wall installations of riser pipes and floor installations. Marking Manufacturer, pipe dimension, batch, blue dot on the press end, yellow pipe plug for 1.4401, green pipe plug for 1.4521, detachable orange label as press indicator from d64.0 Press connector with SC‑Contur Inadvertently unpressed connections become visibly leaky when the system is filled. Viega guarantees the detection of unpressed connections in the following pressure ranges: Min. water pressure: 0.1 MPa / 100 kPa / 1 bar / 14.5 PSI Max. water pressure: 0.65 MPa / 650 kPa / 6.5 bar / 94.3 PSI Min. air pressure: 22 hPa / 2.2 kPa / 22 mbar / 0.3 PSI Max. air pressure: 0.3 MPa / 300 kPa / 3 bar / 43.5 PSI Sealing elements EPDM (ethylene propylene diene rubber), black, pre-​assembled
