Unmanaged ethernet switch DS105

5 portsruggedindustrial

DS105 is a cost effective industrial 5-port Ethernet switch for industrial Ethernet connection. The rugged design can stand for harsh environment and wide temperature (from -40 to 75°C) use. Ultra low power design consumes less than 1W during full traffic. The compact size can fit in for space limited installation such as vehicle wall-mounting or Din-mount for cabinets. Micro USB DC 5V power input is flexible for installation. Ethernet Network Switching ・5-port 10/100BaseTX Ethernet with auto Negotiation, auto MDI/MDIX ・Stores and forwards with non-blocking switch fabric IEEE 802.3az EEE Power Management ・Ultra low power design, less than 1W when full loading ・Energy Efficient Ethernet for low power requirement ・Idle power saving mode for energy efficiency Broadcast Storm Protection & QoS ・Auto drop excessive incoming broadcast packets for network availability protection ・Port-based QoS port for Ethernet Port 4/5 Versatile Power Input and Mounting ・5~30VDC wide range power input ・Micro USB connector for USB DC 5V power input ・Redundant power design: 5~30V/USB 5V ・Support Wall-mount and Din-mount Rugged Mechanical Design ・Ultra compact mechanical design ・Wide operating temperature range -40 ~ 75°C ・CE marking ・IEC61000-6-2/IEC61000-6-4 heavy industrial EMC
