Unmanaged switch IDS205G

5 portslayer 2gigabit Ethernet

The IDS205G is an unmanaged industrial DIN-rail Ethernet switch providing five 10/100/1000Base-T ports in an IP40 aluminum alloy enclosure. Designed for wide-temperature operation and industrial protections, it is suited to rail transit, smart city, intelligent transportation systems and outdoor surveillance applications.

Key features:

• 5-port full-Gigabit Ethernet with Auto Negotiation (10/100/1000Base-T)
• 2K MAC address table
• Store-and-forward switching with non-blocking switch fabric
• Switching capacity: 10 Gbps (Layer 2)
• Overall packet forwarding rate: 7.44 Mpps

Rugged design & protection:

• Industrial-grade fanless cooling for reliable operation in extreme temperatures
• IP40 ingress protection
• Wide operating temperature range: -25°C to 75°C
• Anti-static (ESD) protection: air ±6 kV, contact ±8 kV
• Wide DC input voltage range and dual redundant power support (DC12V–52V)
• Compact DIN-rail mountable form factor

Interfaces & indicators:

• 5 x 10/100/1000Base-TX RJ45 ports (Auto Negotiation)
• System LED: 1 x Power (Red On)
• Ethernet port LEDs: Link (Yellow On), Activity (Yellow Blinking)

Package & ordering:

• Model: IDS205G — DIN-rail 5-Port Gigabit Ethernet Switch
• Package list: 1 x Product unit; 1 x 4-pin removable terminal connector; 1 x attached DIN clip; 1 x quick installation guide
• Optional accessory: MDR-40-24 (power supply: INPUT 85–264 VAC / 120–370 VDC, OUTPUT 24 VDC / 1.7 A, operating -20°C ~ +70°C)

Technical specifications:

• Standards: IEEE 802.3 10Base-T; IEEE 802.3u 100Base-TX; IEEE 802.3 Flow Control; IEEE 802.3z 1000Base-X; IEEE 802.3ab 1000Base-T
• Switch technology: Store-and-forward with non-blocking switch fabric
• Number of MAC addresses: 2K
• Packet buffer memory: 1 Mbit
• Switching capacity: 10 Gbps (Layer 2)
• Overall packet forwarding rate: 7.44 Mpps
• Ethernet ports: 5 x 10/100/1000Base-TX RJ45, Auto Negotiation
• System LED: Power (Red On)
• Ethernet port LEDs: Link (Yellow On), Activity (Yellow Blinking)
• Power input connector: 4-pin removable terminal connector
• Input voltage: DC 12V–52V (dual power supply redundant backup)
• Reverse polarity protection: Yes
• Power consumption: < 2 W (store-and-forward)
• Installation: DIN-rail
• Enclosure material: Aluminum alloy metal
• Dimensions: 57 mm (D) x 78 mm (H) x 25 mm (W)
• Ingress protection: IP40
• Weight: approx. 120 g (without package)
• Operating temperature & humidity: -25°C ~ 75°C, 5% ~ 95% non-condensing
• Storage temperature: -40°C ~ 85°C
• MTBF: 300,000 hours
• Warranty: 3 Year
