Floating ball valve F4 electrically-actuatedcontrolfor acids
Add to favorites
Compare this product
Characteristics
- Type
- floating ball
- Operation
- electrically-actuated
- Function
- control
- Media
- for acids
- Body
- PTFE, PFA
- DN
Max.: 200 mm
(7.874 in)Min.: 15 mm
(0.591 in)- Pressure
Max.: 1.6 bar
(23.2 psi)Min.: 1 bar
(14.5 psi)- Temperature
Max.: 250 °C
(482 °F)Min.: -29 °C
(-20 °F)
Description
There are full bore two-piece floating ball and three piece type fixed ball design. Good sealing performance, minimum pressure drop. Suitable for strong acid, strong alkali medium.
Body material
WCB, CF8, CF8M, CF3M
Leakage class
According to API 598 standard
Cv
186~4200
Lining material
FEP(F46), PFA, PTFE
