Forged chain link

flat toproundconveyor chain

Introduction
Item | DIN 745 Bucket Chain Link | DIN 5699 Bucket Chain Link
Typical Application | Vertical bucket elevators | Flat or inclined scraper conveyors
Basic Design | Round-steel, short-pitch chain; each link carries widened sidebars drilled for bucket bolts | Flat-link chain; thick sidebars accept welded or bolted scraper flights
Common Pitches | 125 mm, 160 mm, 200 mm | 142 mm, 177 mm, 250 mm
Mounting Method | Buckets bolted to pre-drilled sidebar holes | Scrapers welded directly or fixed with connectors
Key Advantages | Even load distribution, fast link replacement, high shock resistance | Wide wear face, strong against bending/torsion, ideal for long scraper runs
Frequent Industries | Cement, grain, fertilizer vertical lifts | Metallurgy, coke plants, waste incineration, ash conveying

Overview
DIN 745 elevator chains & DIN 5699 scraper links—precision forged for vertical and flat conveyor runs.

Parameters (table 1)
Pitch (mm) | Weight (kg/each) | d1 | d2 | d3 | h | a | l | L | D | S | B | MBK values (kN)
45 | 0.17 | 11.5 | 14 | M10 | 40 | 20 | 25 | 75 | 30 | 5 | 10.5 | 76, 106, 98
56 | 0.36 | 15.0 | 18 | M12 | 50 | 25 | 32 | 95 | 40 | 6 | 13.0 | 115, 161, 149
63 | 0.6 | 18.0 | 21 | M16 | 60 | 30 | 40 | 110 | 40 | 6 | 17.0 | 145, 203, 188
70 | 0.9 | 20.0 | 23 | M20 | 68 | 34 | 45 | 120 | 50 | 6 | 21.0 | 179, 251, 232
80 | 1.13 | 23.0 | 26 | M20 | 74 | 37 | 45 | 130 | 50 | 6 | 21.0 | 237, 331, 307
91 | 1.83 | 26.0 | 29 | M24 | 86 | 43 | 55 | 150 | 60 | 8 | 25.0 | 303, 425, 393
105 | 2.4 | 30.0 | 34 | M24 | 100 | 50 | 55 | 165 | 60 | 8 | 25.0 | 403, 565, 523
126 | 3.05 | 36.0 | 40 | M30 | 118 | 59 | 70 | 200 | 70 | 10 | 31.0 | 580, 814, 753
147 | 3.41 | 42.0 | 46 | M30 | 136 | 68 | 70 | 220 | 70 | 10 | 31.0 | 790, 1108, 1025

Parameters (table 2)
Pitch (mm) | Weight (kg/each) | d1 | d2 | d3 | h | a | l | L | D | S | B | MBK values (kN)
35 | 0.17 | 10 | 12 | M10 | 43 | 23 | 25 | 65 | 30 | 5 | 10.5 | 54, 74, 68
45 | 0.36 | 13 | 15 | M12 | 53 | 23 | 25 | 65 | 30 | 5 | 10.5 | 54, 74, 68
45 | 0.36 | 13 | 15 | M12 | 53 | 28 | 30 | 75 | 30 | 5 | 13.0 | 88, 119, 110
56 | 0.60 | 16 | 18 | M14 | 64 | 34 | 35 | 95 | 40 | 6 | 15.0 | 129, 175, 162
63 | 0.90 | 18 | 21 | M16 | 71 | 37 | 40 | 110 | 40 | 6 | 17.0 | 170, 230, 213
70 | 1.13 | 20 | 23 | M20 | 80 | 42 | 45 | 120 | 50 | 6 | 21.0 | 207, 280, 259
80 | 1.83 | 23 | 26 | M20 | 89 | 47 | 45 | 130 | 50 | 6 | 21.0 | 269, 364, 337
91 | 2.40 | 26 | 29 | M24 | 99 | 52 | 55 | 150 | 60 | 8 | 25.0 | 339, 458, 424
105 | 4.20 | 30 | 34 | M24 | 114 | 60 | 55 | 165 | 60 | 8 | 25.0 | 458, 620, 574
126 | 3.05 | 36 | 40 | M30 | 134 | 71 | 65 | 200 | 70 | 10 | 31.0 | 646, 875, 810
147 | 3.41 | 42 | 47 | M36 | 157 | 81 | 75 | 230 | 80 | 12 | 37.0 | 887, 1200, 1110

Standards
Conforms to DIN 745 and DIN 5699 product standards for bucket links and scraper links.

Technical specifications

• Brand: TOPONE CHAIN
• Product: DIN 745 & DIN 5699 bucket/scraper chain links for conveyors
• Typical applications: vertical bucket elevators; flat or inclined scraper conveyors
• Design: precision forged round-steel short-pitch chain (DIN 745) or flat-link chain (DIN 5699) with sidebars for bolting or welding
• Common pitches available: 35 mm, 45 mm, 56 mm, 63 mm, 70 mm, 80 mm, 91 mm, 105 mm, 126 mm, 147 mm (and others)
• Mounting: bolted buckets or welded/fixed scrapers
• Key advantages: even load distribution; fast link replacement; high shock resistance; wide wear face; resistance to bending/torsion
• Industries: cement, grain, fertilizer, metallurgy, coke plants, waste incineration, ash conveying
• Available bolt sizes: M10, M12, M14, M16, M20, M24, M30, M36 (depending on pitch)
• MBK (kN) values provided per pitch in parameter tables
