Chain sprocket wheel

straight-toothedsegment teethconveyor chain

Overview
TOPONE Chain Segment Wheels are modular sprocket wheels intended for bushing-chain and plate-conveyor systems. The reference catalogue presents them both as individual wheel components and as part of complete driving-group assemblies. Segment dimensions, row count, tooth count and driving-group configuration are defined by conveyor design; the catalogue does not provide a standard dimensional table.

Introduction
Segment Wheels are assembled from multiple wheel sectors mounted around a wheel body or integrated into a driving group. They are used in plate conveyors and bushing-chain systems. Typical variants and examples include:

• Segment Wheel Z=15
• Sixfold wheel with 3-inch pitch and 197 teeth
• Special segments for custom profiles
• Segment wheels for plate conveyors
• Driving-group assemblies
• Prepared material for wheel production

Catalogue Parameters
Reference information extracted from the catalogue:

• Product name: Segment Wheels
• Category: Wheels for bushing chains
• Example model: Segment Wheel Z=15 (15 teeth)
• Multiple-wheel example: Sixfold wheel, 3-inch pitch, 197 teeth
• Related components: Special segments
• Conveyor type shown: Plate conveyor
• Assembly: Driving-group assembly or individual components
• Manufacturing item: Prepared material
• Dimensional specifications: Not specified; to be defined from confirmed conveyor drawings
• MOQ: 1 piece
• Packaging: Carton + steel pallet

Standards
The reference catalogue does not list specific manufacturing, testing or maintenance standards for Segment Wheels. Manufacturing requirements, heat treatment, tolerances and testing shall follow the approved conveyor drawings and the confirmed wheel and driving-group configuration.

Technical characteristics

• Brand: TOPONE Chain
• Product: Segment Wheels
• Intended use: Components for bushing-chain and plate-conveyor systems
• Example model: Z=15
• Example tooth count: 15 (catalogue example)
• Multiple-wheel example: Sixfold wheel (197 teeth, 3-inch pitch)
• Related components: Special segments
• Assembly type: Driving-group assembly or individual wheel components
• Conveyor type: Plate conveyor
• Manufacturing item shown: Prepared material
• Dimensional specifications: Determined from confirmed conveyor drawings
• MOQ: 1 piece
• Packaging: Carton + steel pallet
