Horizontal injection molding machine PS5

hydraulicmodularfor thin-walled parts

Overview
The PS5 Series high-speed injection molding machines are engineered for high-throughput, precision molding of thin-wall and high-volume components. Suitable for food packaging, medical disposables, bottle caps and consumer chemical containers. The machines combine an optimized control system, enhanced cylinder sealing and reinforced platens to deliver repeatable high-speed performance with a maximum injection speed of 550 mm/s and a clamping force range of 2800–5600 kN.

Highlights

• High-speed, low-pressure injection optimized for thin-wall molding
• Energy-efficient hydraulic design
• Industrial-grade components for reliable continuous operation
• Modular options for synchronized mold opening and ejection

Clamping Unit

• High-rigidity clamping unit with reinforced platen optimized by finite element analysis for improved platen stiffness and reduced stress
• Anti-tilt movable platen support to maintain platen parallelism during heavy or high-speed cycles
• Steel and copper bushings to reduce lubricant consumption and ensure consistent lubrication of toggle pins and tie bars

Injection Unit

• High-speed injection design with multi-action compound operation; max injection speed up to 550 mm/s
• High-speed, high-pressure plasticizing motor for improved melt quality and extended service life
• Dual linear guide carriage with integrated cast-iron support to reduce friction and shorten injection acceleration time

Hydraulic System

• Optimized hydraulic oil circuit to reduce pressure loss and improve energy efficiency
• Standard multi-pump circuit with mold opening synchronized to plasticizing; mold opening synchronized with ejection available as an option

Control System

• Major hydraulic and electrical components sourced from leading international suppliers to ensure stability
• Intelligent mold opening with simplified start/end parameter setting and automatic optimization
• Adaptive clamping force management for proactive setting, monitoring and optimization of clamping parameters

Product Video (titles)

• Machine Introduction
• 700 ml Labeled Milk Tea Cup
• Plastic Sauce Container
• Tamper-proof Bucket

Industry Applications

• Food packaging
• Medical disposables
• Bottle caps
• Daily chemical products

Technical specifications

• Series / Model: PS5 Series
• Max injection speed: up to 550 mm/s
• Clamping force range: 2800–5600 kN
• Optimized control system and enhanced cylinder sealing
• High-rigidity reinforced platens (FEA optimized)
• Anti-tilt platen support for improved parallelism and long-term stability
• Steel and copper bushing design to reduce lubricant consumption
• Low-pressure, high-speed injection and multi-action operation for thin-wall products
• High-speed, high-pressure plasticizing motor
• Dual linear guide carriage with integrated cast-iron support
• Optimized hydraulic circuit to reduce pressure loss and increase energy efficiency
• Multi-pump hydraulic circuit with synchronized mold opening; ejection-synchronized opening optional
• Imported major hydraulic and electrical components
• Intelligent mold opening: two-point parameter setting with automatic optimization
• Intelligent clamping force management for proactive monitoring and optimization
