Helical gear pump MPB1000

for chemicalsfor food productsmagnetic-drive

Short description
MPB1000 is a micro magnetic-drive gear pump driven by an AC brushless servo motor. Displacement 33 ml/rev, flow up to 100 L/min, typical outlet pressure range 0.5–5 bar. Designed for high-speed, accurate control, stable operation and applications requiring leak-free fluid isolation.

Key features

• No-pulse accurate delivery
  Helical gear pair provides continuous, pulse-free fluid transfer. With servo control, delivery accuracy reaches ±0.2%.
• Strong suction and stable pressure
  Capable of effective suction under vacuum and stable discharge for low-viscosity liquids at high throughput.
• No external leakage
  Magnetic drive with static O-ring sealing isolates pumped medium from atmosphere to prevent leaks.
• Low noise and energy efficient
  Magnetic coupling transmits torque without mechanical contact. Helical gears reduce friction and vibration; motor output is adjusted to load to save energy.
• Long service life
  High-performance materials and brushless motor design remove carbon brushes, extending maintenance intervals.

Pump description
The MPB1000 uses an AC brushless servo motor coupled via an outer-ring magnetic circuit (magnetic coupling). An external controller enables closed-loop control of speed, torque and position for precise dosing and dynamic response, suitable for frequent starts/stops and high-speed operation.

Model specification
Model series: MPB (rubber O-ring seal). Displacement: MPB600 = 15 ml/rev (max 45 L/min); MPB1000 = 33 ml/rev (max 100 L/min). Pump body materials: 304 / 316L / PPS / Hastelloy / Titanium. Gear/shaft options: PEEK gear with 316L/ceramic/tungsten/titanium shafts; 316L gear + 316L shaft. Inlet/outlet thread: chuck. Motor options: BL (brushless DC), DC (brushed DC), SVCA (servo), ACIM (3-phase AC induction), explosion-proof variants. Voltage: 220V. Power options: 400W / 750W / 1000W (this page: 750W servo).

Technical parameters
Typical configuration example: MPB1000 B A E D 220V 750W. Medium viscosity range: 0–12,000 cps. Medium temperature range: -40°C to 100°C. Outlet pressure: up to 0.5–5 bar (application dependent); reference pressure difference: 3 bar. Inlet vacuum: -0.85 bar. Motor speed range: 0–3000 rpm. Delivery accuracy with servo control: ±0.2%.

Applications & additional notes
Suitable for filling, dosing, food-grade transfer, viscous-fluid handling and any application requiring magnetic isolation to prevent leakage. Select materials and shaft/gear combinations according to chemical compatibility and temperature requirements.

Technical specifications

• Model: MPB1000
• Displacement: 33 ml/rev
• Flow range: up to 100 L/min (model dependent)
• Typical outlet pressure: 0.5–5 bar
• Reference pressure difference: 3 bar
• Inlet vacuum capability: -0.85 bar
• Medium viscosity: 0–12,000 cps
• Medium temperature: -40°C to 100°C
• Body materials: 304 / 316L / PPS / Hastelloy / Titanium
• Gear & shaft options: PEEK gear with 316L/ceramic/tungsten/titanium shafts; 316L gear + 316L shaft
• Motor types: brushless DC, brushed DC, servo, 3-phase AC induction, explosion-proof variants
• Voltage: 220V
• Power options: 400W / 750W / 1000W (example: 750W servo)
• Delivery accuracy: ±0.2% (with servo)
