DMR6 - 2DMR6 - 2DMRV:
Single-geared presses, one or two connecting rods, with fixed or variable stroke, equipped with Balconi Plunger system. These presses are designed for stamping of middle thick materials by using progressive tools of small and medium sizes. The press series includes machines from 700 kN to 4.000 kN.
2DMRF - 4DMRF:
Single or double-geared presses with two or four connecting-rods, fixed or variable stroke, equipped with Balconi Plunger system. These presses are designed for stamping of middle and heavy materials by using progressive tools of medium and large dimensions. The press series includes machines from 2.500 kN to 16.000 kN. Together with these presses Balconi can also supply its own band feeding lines, completely integrated with the press, for coil width from 800 to 1.800 mm.
2DMR-TR:
Presses equipped with 2 or 3 axes mechanical or electronic transfer systems. |
|
Transfer systems for the transport of parts with the help of gripper rails in the complete sector of non-cutting shaping.Our transfer systems combine both the individual tools of a transfer press, as well as linking individual presses.
In accordance with the existing technical capabilities and customer needs are different sizes and variants feasible.
The equipment are based on our approved mechanical subgroups and a modern control and drive technique. The control control systems are preferably equipped with integrated Siemens components. By request are other control units available, for example by Allen Bradley.
Our transfer systems are fee-programmable which means that the positions and the displacement courses of the gripper rails (closing, lifting and transport) can be determined by the program within the limits of the technical data. According to the application or the specification the individual servodrives are synchronised either to each other or to the press run.
|
|
... see all the products in the category
Presses
|
| LINE OF INSTALLATION - Auto industry - PINS - ELECTRIC PRESS FORCES 4 TONS (details to see FILE pdf BY BOND Internet) |
|
Each industry has its own requirements with regard to pressing material, pressing volume etc. The solutions shown here present the classical and frequently used system recommendations. Many HSM system solutions can do much more - and are suitable for almost all requirements - than the uses displayed here. Inquire if you have other materials or uses. We will find the suitable solution. Together with all detail solutions, each user gets the maximum benefits. Long service life, economic efficiency, operator friendlyness, high pressing power - these are the typical plus points that each HSM bale press can be credited for.
|
|
The GHT 4x4 is the total traction filter press with high productivity. The filter plates, which are hung from the upper beam, are moved automatically by a rapid shifting device equipped with a carousel system which reduces the filter press opening and closing sequence to the minimum. Four hydraulic cylinders placed on the plate pack corners ensure perfect operation and limited structural stress, even in the most unfavourable working conditions. Different from the traditional push-type systems, the “total traction” system does not transmit any stress to the upper beam, which is only subjected to weight of plates supported from it. In fact, the forces applied by the closing device are subjecting the tie beams to tension, which avoids stress on the frame and consequently, the risk of structural deformation. Effectively guarded moving parts and the use of state-of-the-art electronic interlock systems mean that the GHT 4x4 conforms to the highest operator health and safety regulations. Routine maintenance operations are simple, thanks to easy access to the filter plates, both for inspection and for filter cloth replacement.
|
|
The GHT 4x4 is the total traction filter press with high productivity. The filter plates, which are hung from the upper beam, are moved automatically by a rapid shifting device equipped with a carousel system which reduces the filter press opening and closing sequence to the minimum. Four hydraulic cylinders placed on the plate pack corners ensure perfect operation and limited structural stress, even in the most unfavourable working conditions. Different from the traditional push-type systems, the “total traction” system does not transmit any stress to the upper beam, which is only subjected to weight of plates supported from it. In fact, the forces applied by the closing device are subjecting the tie beams to tension, which avoids stress on the frame and consequently, the risk of structural deformation. Effectively guarded moving parts and the use of state-of-the-art electronic interlock systems mean that the GHT 4x4 conforms to the highest operator health and safety regulations. Routine maintenance operations are simple, thanks to easy access to the filter plates, both for inspection and for filter cloth replacement.
|
|
AUTOMATIC STRAPPING MACHINE PR 99
The automatic strapping machine PR99 is suitable for the vertical compression of palletized loads of paper, cardboard and paper bags.
It is provided of two strapping heads and three arches and it can carry out two strapping operations in automatic mode with a prefixed distance.
One of the two head, which is mobile, allows to set the distance between strappings.
The lower retractable channel allows to carry out strappings, positioning the cargo to the wooder pallet.
The complete device version for the automatic pallet rotation allows to perform cross strappings too.
The machine is managed by PLC; it is also furnished with a pressing device which is commanded by moving rack.
It has a touch screen operator on the control panel by which it is possible to manage the machine: how it works and to set up the type of strap you need, choosing between polypropylene or polyester strap.
POWER SUPPLY 400 Vac, 50Hz or customized upon request
COMPRESSION 3000kg (standard) to 5000kg
TYPE OF USABLE STRAPPING BAND PP with 12 to 19 mm width, 0.80 to 1mm thicknessPET with 9 to 19 mm width, 0.60 to 1 mm thickness
STRAPPING CYCLE TIME 15 to 22 seconds for two simultaneous strappings, depending on the package size and press amount |
|
| The Power master 10481 is a high performance strapping press of the most recent generation, manufactured in our plant in Wuppertal. With an infinitely adjustable compression automatic height seeking of incoming loads for faster troughput and numerous variations of pallet and load handling equipment for feed, center and turn the Sander power master can be integrated very easy in automatic packing lines. As a special feature the electric motor driven compression platen includes a permanent accurate compression sensing which is a requirement in the corrugated and paper industry. This ensures an intermittent further compression cycle. Both PET or PP strapping material can be used with the machine. The Sander GS-41 strapping head guarantees a solid vibration seal joint without any emissions of vapors. |
|
Automatic strapping machine with air pressure
FEATURES:
Top press mechanism
Stainless steel table top
2 air cylinders,dia .100 mm ,stroke: 550 mm
Front & rear acrylic protect cover
Power supply: 3 phase 220V,380V,415V,440V(50/60Hz)
Arch size: W 1250 x H 700 mm
Strap width: 9,12,15, 19 mm (option)
Strap Tension: max.70 kgs (100 kgs option)
Pressure: 550kgs (made on request)
Strapping Speed: 2.4 sec/strap (exclude time of top press up and down)
Machine size: L 2170 x W 800 x H 2463 mm |
|
|
|
