Complete solutions for MIL-STD-1553 network
Axon' has developed different components such as data bus couplers, cables and connectors to the MIL-STD-1553 standard for data bus transmission systems for on-board aeronautic, space systems and military applications.
Advantages
- Qualifications :
MIL-STD-1553B, ARIANE5, Digibus, EN3567 specification, EFA programme specification,
- Space programmes :
COLOMBUS, ATV, ISS (CNES & ESA approvals, BOEING & NASA approval for the ISS) , EUROSTAR3000
- IEEE1394 (FireWire), IEEE 1355, Space Wire, Fibre channel
- EMC / EMI
- Weight and space savings
For space applications, the assembly of components is carried out in a class 100000 clean room
Control
- MIL-STD-1553-B axon test bench harness validation
- For high speed data rate transmission eye diagrams with jitter, Bit Error Rate, eye opening measurements available
- EMC / EMI test bench for cables & connectors
Construction
- Databus screened twisted-pair cables or quads
- Databus cables according to MIL, EN or customer specification
- High speed data bus cables with screened parallel pairs
- In-line micro-couplers or removable couplers from 1 stub to 8 stubs
- QPL relay or coupler relay
- Bus terminators
- Splices with controlled impedance
- range of MIL-STD-1553 connectors
- Stub loads and various accessories
- Customised products
Applications
- MIL-STD-1553B databus network
- High speed data rate transmissions
- Cabling of rockets, aircraft, satellites, space vehicle, orbital facility, helicopters, tank, military ground equipment
|
|
Due to the increasing data transfer between machines and equipment the higher standards in data and computer applications are necessary.
Besides standard processes the requirement of precise data transfer must be the first and foremost.
Depending on the requirement, the HELUKABEL® customer can choose the data or computer cable from an extensive stock, where almost all cable constructions are ex stock.
If solid, flexible or high flexible constructions, with corresponding screening if necessary, this all depends of the required application. Our technical advisers are ready to inform you.
We can also manufacture cables according to your specific requirements with a minimum order quantity. For special enquiries please fill-in our attached enquiry form.
|
|
Cat 6 23/4pr solid BC
ETL Verified, Tested to 600 MHz
Cat 6 23/4pr solid BC
Plenum Rated
ETL Verified, Tested to 600 MHz
|
|
As supplier of underground cables, telephone cables for indoor and outdoor lying, as well as fi re warning cables HELUKABEL® provides for a short term delivery-readiness. Modern and powerful cutting machines ensure even the demands for fi xed lengths within a short term processing.
To the nearness of our customers (stock in Hemmingen/Stuttgart, Neuenhagen/Berlin, Pleißa/Chemnitz and Windsbach/Nürnberg) we are also as direct deliverer to the customers construction sit for short scheduled term onthe- spot.
On request we deliver also vehicles with lifting platform for better loading and unloading.
|
|
DATA COMMUNICATION SYSTEMS
Lapp produces a full range of data cables for fast and secure transfers of large volumes of data. From machine electronics and bus systems to super-fast LAN data networks or highly-versatile applications: We have the data cables you need for virtually any situation.
|
|
1. DATA CABLES
• UTP (unshielded).
- Cat. 3. Multipair ( 25, 50 and 100 pairs).
- Cat. 5e, Cat 6. Simple or dual.
• FTP (shielded).
- Cat. 3. Multipair ( 25, 50 and 100 pairs).
- Cat. 5e, Cat 6. Simple or dual.
• Structured wiring system.
Standard of manufacture:
ISO-IEC 11801, CENELEC 50173, ANSI/EIA/TIA 568.
2. TELECOMUNICATION CABLES
Twisted pairs from 1 up to 2400 pairs.
• Metallic cables for external Networks.
• Metallic cables for indoor (switchboard).
3. FO CABLES
|
|
DATA COMMUNICATION SYSTEMS FOR ETHERNET-TECHNOLOGY
The Lapp Group is now in a position to offer comprehensive system solutions in the field of industrial networking. Its Factory Automation division supplies active network components that are used to supplement existing cable and plug technologies. These include services and security systems incorporating firewall solutions, in addition to distribution components such as switches, routers, cables and plug connectors. For its industrial customers, all of this means that a solution from the Lapp Group represents a considerable step forward in terms of security, safety and availability.
|
|
PVC data cables
PVC data cables with overall copper screen
PVC data cable extra fine wires with overall copper screen
PVC data cable with pair-wise and overall copper screen
Semi rigid PVC data cable acc. to UL
Semi rigid PVC data cables with overall copper screen acc. to UL
Semi rigid PVC data cables acc. to UL
FEP insulated Koax cable
|
|
|
Amphenol is a global provider of interconnect solutions to designers and manufacturers of internet enabling systems. Amphenol's range of offerings in electrical and optical cable, cable assembly, connector products and backplane interconnect systems span applications in PC's, servers, storage systems, optical and copper networking equipment, modems, hubs, routers, switches, media display systems, and internet appliances. With our design creativity and cost effectiveness, Amphenol leads the way in interconnect development for internet equipment, infrastructure, enterprise networks and appliances. Whether industry standard or application-specific designs are required, Amphenol provides customers with products that enable performance at the leading edge of next generation high-speed technology.
|
|
Halogen-free single conductors
Halogen-free control cables
Halogen-free control cables acc. to UL
Halogen-free connection cables 0.6/1 kV
Halogen-free data cables
Halogen-free cables especially for use in rail vehicles acc. to EN 50306
|
|
HellermannTyton offers a full range of coppper connectivity products including patch panels, jacks, faceplates, and patch cords. Continually updated, these products meet the latest industry standards, and aggressive system and product warranties are offered with this line.
When using HellermannTyton modular jacks, patch panels, and patch cords with an approved horizontal cable manager, the Gigaband® Category 6 and Megaband®Category 5e systems far exceed the TIA requirements for structured cabling systems. Both systems have been independently tested to perform better than required by the respective Category 6 and 5e standards.
|
|
|
Telecommunication cable for local networks and PABX, used for telecommunication and data transmission. Suitable for laying in ground or in cable ducts
|
|
XTRA•GUARD®
HIGH PERFORMANCE ELECTRONIC CABLES
IIn today's world of sophisticated electronics, every application is critical! Computers efficiently monitor and control multi-million dollar production lines and processes.
The integrity of your system is only as solid as the electronic cable on which the control signals are communicated. If the cable fails, your system is down. Production time . . . efficiency . . . profits . . . lost.
If you think that wire and cable is just wire and cable . . . think again.
The cable you install must be capable of efficient signal transmission while it withstands the environmental abuses of heat or cold, intermittent or continuous motion, abrasion, immersion in oils or EMI/RFI interference.
|
|
Cabelte starts the production of copper telecommunication cables since the early 1970’. The first copper cables were made of PVC insulated conductors twisted in pairs.
The rise of the new generation of cables with better characteristics for transmission, takes place in the 80s with the use of solid and cellular polyethylene as insulation material.
Today, the use of copper telecommunication cables embraces other applications, as a result of the progress revealed on transmission systems. In the’ 90s, a new generation of cables for customer premisses appears, adapted,not only for voice, but also for image and data transmission, with optimized performance capable of supporting high transmission rates.
|
|
CC-Link ensures high-speed communication between data and field devices (such as controls, sensors or actuators) at the control and field level.
Thanks to a wide range of automation devices from various manufacturers, communication can be provided along a single cable, thereby facilitating integrated and effective production.
|
|
Cabelte starts the production of copper telecommunication cables since the early 1970’. The first copper cables were made of PVC insulated conductors twisted in pairs.
The rise of the new generation of cables with better characteristics for transmission, takes place in the 80s with the use of solid and cellular polyethylene as insulation material.
Today, the use of copper telecommunication cables embraces other applications, as a result of the progress revealed on transmission systems. In the’ 90s, a new generation of cables for customer premisses appears, adapted,not only for voice, but also for image and data transmission, with optimized performance capable of supporting high transmission rates.
|
|
New railway cable generation (January 2004) according to European standard EN 50200. Operability in the case of fire. Bus and control cables, protected, halogeneous-free, flame-adversely.
2-pairs (star quad) bus cable with 0,5mm² conductor cross section, radiation cross-linked Foam Skin PE isolation, plastic laminated aluminum foil, tinned cu network and halogeneous-free, flame-adverse, radiation cross-linked outer casing. Been suitable e.g. as devices connection cable for the transmission from digital signals to to a Baud rate of 10M Baud within of railway vehicle.
General features
- Conductor: flexible
- Insulation: oil resistant, gasoline resistant, halogen free
|
|
Temperature Resistant Cable
silicone insulated:
- temperature resistant, flexible Cable, silicone insulated, 0,5mm², 0,75mm², 1,5mm², halogen free
halogen free, highly flexible:
- halogen free, highly flexible Control Cable, twisted pairs resp. cores, 0,25mm² and 0,5mm², outer shielding, silicone jacket, red, 1 cored to 4 paired
Teflon insulated and shielded:
- temperature resistant, flexible Cable, 0,06mm², 0,24mm², 0,38mm², 0,56mm², The cables are: Teflon-PTFE isolated, shielded, possess a white protected jacket from Teflon-FEP.
|
|
Communications Cable, solid wire 0,6mm diameter, foil shielded with added wire, VDE 0815, DIN 57815, 2 to 100 pairs
General features
- Conductor: solid
- Insulation: oil resistant, gasoline resistant, cold resistant
- Overall shielding: 100% shielding to exterior influences
- Cable jacket: oil resistant, gasoline resistant
|
|
The telecommunications copper cables range contains pair cables for the local networks, quads cables for central connections, cables for the subscriber network, PCM cables and data cables for LAN networks.
Significant part of these cables corresponds to constructions specified by the two main telecommunications operators of the Iberian Peninsula.
However, similarly to the remaining ranges, it is possible to project constructive solutions taking into account special customer’s requirements.
|
|
CAN was originally made for the automotive market but in the meantime it is being used more and more as a system cable for industrial applications.
The CAN-Bus cable is applied for the exchange of digital information, control apparatus net for faster data transmission.
|
|
PVC Electronics cables
LiYY
LiYCY
LiYCY paired
PVC electronics cables, individually screened pairs
Interface cables for industrial use
UL/CSA listed PVC electronics cables
UL/CSA listed 'Low Capacitance' PVC electronics cables
|
|
