MTM Power GmbH, the specialist for individual power supplies, offers DC/DC converters for worldwide industrial application with an output power from 1,5 to 200 W. They are available with input voltage ranges of 2:1 and 4:1 and output voltages between 1,8 V and 48 V as single, dual and triple output and also as costumized versions. The converters are built in a plastic or metal case. The different cases are DIL 24 or SMD up to 10 W, 2" x 1" cases up to 20 W, 2" x 2" cases up to 30 W, quarter brick with 75 W, half brick with 50, 75, 100 and 150 W and full brick cases with 200 W. Further features are high efficiency of up to 94 %, low ripple&noise, isolation up to 3 kVDC as well as various options like external output voltage trimming and remote control.
|
|
|
|
|
|
AM1DC-Z series of DC-DC converters provide ultra high I/O isolation of 6000 VDC with an isolation barrier of 2.5mm, providing supplemental isolation.
Input voltages of 5, 12 and 24 VDC converts to single and dual output voltages of (¡Ó)3.3, (¡Ó) 5, (¡Ó)9, (¡Ó)12 and (¡Ó)15 VDC with continuous short circuit protection. Operating at efficiencies as high as 79% within an ambient temperature range of -40„aC to +71„aC at full load or up to +85„aC with derating, the AM1DC-Z series is well suited for both indoor and outdoor industrial applications including motor control, test and measurement.
Designed in a compact SIP7 package (19.56 x 9.90 x 12.45mm), the AM1DC-Z ¡¥s I/O isolation barrier (2.5mm) meets the specifications outlined in the IEC 60950-1:2001 safety standard ITE (rated for 250VAC working voltage), allowing these converters to be used in multitude of space critical applications.
Made with high quality, RoHS compliant materials that undergo rigorous quality control to ensure reliability and performance, the AM1DC-Z series is competitively priced at $7.04/1000+ pieces with samples available from stock for immediately delivery.
|
|
|
|
|
|
|
The new primary switched DC/DC converters with 250 W and 400 W output power of MTM Power GmbH are especially designed for automotive applications. They operate according to the push-pull principle, i. e. the input dc-voltage is chopped by two push-pull working transistors with a frequency of approx. 60 kHz. With the help of a transformer and a secondary linear choke, a galvanically isolated output voltage (12 V or 24 V) is produced which is adjusted by pulse-width modulation according to the current mode principle. The series PCMD250W and PCMD400W are available with input voltages of 24 VDC (16,8…36 VDC), 80 VDC (50…150 VDC) or 110 VDC (66…154 VDC) and can be connected via screw connectors. The dimensions are 150 x 86 x 55 mm (L x W x H). Due to this compact design, they are also suitable for applications where only little space is available. The converters need no ground load, are maintenance free and short-circuit protected by primary and secondary power limitation. They are vacuum potted and prepared for the use in devices with Protection Class. As an option, they are available for the use in railway applications. Further features are a mechanically and electrically rugged design using SMD-technology and an automatic piece-by-piece test.
|
|
|
|
|
|
|
These primary switched DC/DC converters of MTM Power GmbH, the specialist of individual power supplies, are especially designed for automotive applications and operate according to the push-pull principle, i. e. the input dc-voltage is chopped by two push-pull working transistors with a frequency of approx. 70 - 100 kHz. With the help of a transformer and a secondary linear choke, a galvanically isolated output voltage is produced which is adjusted by pulse-width modulation according to the current mode principle. The converters need no ground load and are short-circuit protected by primary and secondary power limitation. The converters are maintenance free, vacuum potted, prepared for the use in devices with Protection Class II and fulfill the low voltage directive. They show a mechanically and electrically rugged design using SMD-technology and undergo an automatic piece-by-piece test. To ensure a smooth operation, it is necessary to mount the converters on a heat-dissipating surface. The converters are available with 75 W, 120 W, 150 W and 200 W output power and the following connecting types: flying leads or screw connectors.
|
|
The continuously growing number of electric and electronic applications in vehicles demands constant and maintenance-free supply.
MTM Power has developed a new generation of DC/DC converters with 80 and 150 Watt output power; these converters are especially designed for applications in vehicle and rail technology but also for use in industrial and telecommunication applications. This new model range allows input voltages of 9/14.4...154 VDC, in various voltage ranges, thereby covering all common battery sets. Typical input voltage ranges are, among others, according to EN 50 155, 14.4...33.6 VDC (24 VDC nominal), 21.6...72 VDC (36/48 VDC nominal) and 43.2...154 VDC (72/110 VDC nominal). Input voltage ranges deviating from these can be realised specifically for the customer at any time.
|
|
|
|
|
|
|
The product family PMG/PCMG with DC input voltage completes the range of primary switched MTM Power Modules. The modules offer an input range of 20...72 VDC and allow - due to the different types available in this series - efficient solutions in numerous application fields. They are available with single, dual or triple outputs. The single and dual (sym.) versions are UL 60 950 and UL 508 approved. Dimensions are 90,5 x 65,5 x 33,5 mm for PCB-mounting (PMG) and 120,0 x 65,5 x 33,0 mm for chassis mounting (PCMG). Thus, they offer the same dimensions and pinning as the standard AC/DC and low voltage modules of the same wattage range which allows the customer to design only one layout for standard AC, low voltage and DC input. The vacuum encapsulated devices offer an isolation of 3,3 kVrms and comply to the up-to-date EN standards as regards CE conformity. Further features are rugged design, SMD-technology, automatic 100 % final test and 100-%-burn-in-test. The series PMG/PCMG offers 15 W or 30 W constant output wattage, is short circuit protected and needs no ground load.
|
|
|
|
|
|
Aimtec strengths its low output power product offering with the addition of its AM1G-Z and AM2G-Z series of single and dual output DC-DC switching power supplies with operating temperature range -40.+85ºC. With output currents of up to 303mA delivered to regulated output voltage range of 3.3 to 24V, at high efficiency rates of up to 78%, the AM1G-Z and AM2G-Z series is ideally suited for portable power management applications, in addition to other telecom, industrial, datacom and transportation equipment applications.
Versatile, single and dual output modules are available in 2:1 input ranges of 4.5-9V, 9-18V, 18-36V and 36-72V with I/O isolation of 1000 and 3000VDC within a compact SIP8 package. The AM1G-Z and AM2G-Z series feature many functional advantages, including continuous short circuit protection and remote on/off control. Designed to allow the output voltage to shut-off without shutting down the input voltage, the remote ON/OFF function in Aimtec's AM1G-Z and AM2G-Z series is supports applications where conservation of the device's power consumption is required and/or there is a need for the power supplies to switch ON and OFF in a specific sequence. Made with high quality, RoHS compliant materials that undergo rigorous quality control to ensure reliability and performance, samples are available from stock and can be ordered immediately.
|
|
|
|
|
|
Aimtec strengths its low output power product offering with the addition of its AM1G-Z and AM2G-Z series of single and dual output DC-DC switching power supplies with operating temperature range -40.+85ºC. With output currents of up to 303mA delivered to regulated output voltage range of 3.3 to 24V, at high efficiency rates of up to 78%, the AM1G-Z and AM2G-Z series is ideally suited for portable power management applications, in addition to other telecom, industrial, datacom and transportation equipment applications.
Versatile, single and dual output modules are available in 2:1 input ranges of 4.5-9V, 9-18V, 18-36V and 36-72V with I/O isolation of 1000 and 3000VDC within a compact SIP8 package. The AM1G-Z and AM2G-Z series feature many functional advantages, including continuous short circuit protection and remote on/off control. Designed to allow the output voltage to shut-off without shutting down the input voltage, the remote ON/OFF function in Aimtec's AM1G-Z and AM2G-Z series is supports applications where conservation of the device's power consumption is required and/or there is a need for the power supplies to switch ON and OFF in a specific sequence. Made with high quality, RoHS compliant materials that undergo rigorous quality control to ensure reliability and performance, samples are available from stock and can be ordered immediately.
|
|
|
|
|
|
|
MTM Power GmbH, the specialist for individual power supplies, has designed a new generation of DC/DC converters: the series PCMDS60W. They can especially used in automotive applications. These primary switched DC/DC converters are available with an output power of 60 W and operate according to the push-pull principle, i. e. the input dc-voltage is chopped by two push-pull working transistors with a frequency of approx. 70 kHz. With the help of a transformer and a secondary linear choke, a galvanically isolated output voltage (5,2 V, 12 V or 24 V) is produced which is adjusted by pulse-width modulation according to the current mode principle. The converters are available with a wide input range for battery voltages of 24 V, 36 V, 72 V, 96 V and 110 V acc. EN 50 155. The dimensions are 130 x 69 x 30 mm (length x width x height). Because of this flat design, they are also suitable for applications where only little space is available. The maintenance-free converters are connected via spring clamps, which meet the special requirements e. g. in railway applications as regards to vibration resistance and reduced time for wiring.
|
|
MTM Power GmbH, the specialist for high quality power supplies, offers in its program the new DC/DC converter series URC for automotive applications. Due to the ultra wide input range of 14,4…154,0 VDC, the 50 W or 75 W converters can be operated at all standard battery voltages (24 / 36 / 48 / 60 / 72 / 110 VDC ±40 %) in railway vehicles acc. to EN 50 155 and in stationary applications. There are 8 different versions with single, dual or triple outputs available. The converters can be used for 19" rack or wall mounting with H15 connector and can be switched on and off by the enable input. Further features of the URC series are input and output voltage monitoring, high temperature range, high reliability and long life.
|
|
|
|
|
|
|
MTM Power GmbH, the specialist for high-quality power supplies, offers in its program DC/DC converters for railway applications of the series HVC with 150 W and 250 W. These devices are available with an input range of 400…975 VDC and the standard output voltages of 24 VDC and 36 VDC. With these high voltage converters it is possible to supply electronical equipment out of 600 V / 750 V contact wire. The DC/DC converters are used for supplying points, signal lamps and electronic monitoring of the rail net. The specific feature of the series HVC is its use as a self starting module for trams or trolley buses with exhaustive discharged batteries so that the towing process can be avoided. The rugged design together with high-quality components guarantee the high reliability in vehicles even under severe shock and vibration conditions. The high efficiency of 83 % allows an operation without forced ventilation. Moreover the converters work with an ambient temperature range from –40…+85 °C acc. to EN 50 155.
|
|
|
|
|
|
The HVI 2K is a recent addition to Absopulse Electronics line of rugged, high input voltage DC/DC converters. This design uses field proven technology to generate 2kW output power, and accepts a 600Vdc input voltage (450V to 800Vdc range). This single output unit delivers 12V/130A, 24V/80A or 48V/40A, with other outputs available on request. An optional built-in redundancy diode allows for parallel and N+1 operation. The HVI 2K is suitable for rugged applications including in industrial plants, alternative energy conversion (such as solar cells) and electric vehicles.
To ensure high reliability and long operating life, all critical components on the primary side are designed and tested for corona inception levels significantly higher than the operating voltage. The HVI 2K is filtered to meet EN55022 Class A EMI conducted and radiated and it is designed to meet IEC61010-1
Ed. 2, IEC 62103 Ed. 1, UL 508C and related standards.
This compact design measures 187 x 132 x 407 mm (7.4” x 5.2” x 16") and can be chassis or 19” rack mounted. Built-in fans provide sufficient airflow for operation over 0°C to 50°C temperature range for full specification, with wider temperature ranges available. Other options include heavy ruggedizing and conformal coating for operation in extreme environments.
|
|
|
|
|
|
Absopulse Electronics designs and manufactures rugged, high performance DC-DC converters for almost any input/output and mechanical configuration requirement, with output power ranging from a few watts to over 30kW. These converters are suitable for a wide range of environments, including railway, industrial, military, marine, airborne, utility and telecommunications.
Absopulse's railway power supplies are designed to meet rail-specific standards including EN50155 and EN50121-3-2. They are typically encapsulated in a in thermally conductive MIL-spec. silicon rubber compound to ensure immunity to shock, vibration, moisture, salt and airborne contaminants. These encapsulated units operate in ambient temperatures ranging from -40°C to +85°C and humidity up to 95%, and are conduction/convection cooled.
Our rugged, dc-dc converters offer:
- DC inputs: 12Vdc, 24Vdc, 36Vdc, 48Vdc, 72Vdc, 96Vdc, 110Vdc and custom
- High input voltages up to 800Vdc
- DC outputs: 3.3Vdc, 5Vdc, 12Vdc, 15Vdc, 24Vdc, 36Vdc, 48Vdc, 125Vdc 250Vdc and custom
- High output voltages to 800Vdc available
- EMI filtering to meet any standard
- Conformal coating or encapsulation (potting) to ensure immunity to shock, vibration, humidity, moisture, dust and insects available
- Operating temperature ranges including -40°C to +85°C available
- Full electronic protection
- Alarms (form C contacts) option available on most designs
|
|
|
Typical applications include: installations of mobile and cellular radio communications equipment, telemetry systems, refrigeration, televisions etc on trucks, buses, forestry and off road vehicles as well as boats and yachts and a variety of industrial applications.
|
|
|
Typical applications include: installations of mobile and cellular radio communications equipment, telemetry systems, refrigeration, televisions etc on trucks, buses, forestry and off road vehicles as well as boats and yachts and a variety of industrial applications.
|
|
24Vdc to 12Vdc Converters
These products offer a convenient way to operate mass produced 12Vdc equipment, such as cell phones, in car entertainment equipment, professional communication equipment, telematics equipment, refrigerators, televisions, etc. from the 24Vdc mobile electrical systems found on diesel engined vehicles and vessels and the 28Vdc systems found on aircraft.
These cool running products use switch mode technology and are assembled using surface mount technology.
All the products are CE marked, e marked and meet the requirements of
FCC Class B.
|
|
Chassis mount DC/DC converters, cooled by fan or air circulation, compact design, high power:
- 25W to 350W
- Input voltages from 9,2V to 144V
- Output voltages 5V, 12V, 24V, 48V
|
|
Customer specific power supplies and power conversion systems
Our professional development engineers solve even the most difficult problems in accordance with your specifications.
Based on our thorough experience and development process, we have become experts for our customers when it comes to packaging power supply solutions. In this way we can relieve our customers of development and application expenses and provide the necessary environment for trouble-free operation of their devices by using our highly reliable power supply units.
Our vast experience provides a great platform for us to deliver industry specific power supply solutions.
Whether it involves meeting the demands of the rail industry, or under-standing the issues faced by communications engineers, Zentro-Elektrik has the expertise to provide application know how, working with customers from conception through to manufacture of a safe and reliable power supply solution.
|
|
Compact DC/DC converters for DIN rail and wall mounting
At 100 Watt and 500 Watt the latest DC/DC converters from Zentro Elektrik extend the existing comprehensive range of converters.
The compact DC/DC converters are designed for applications in automation engineering, power supply and power station engineering, in traffic systems and railway in particular, and in mechanical engineering. They are air-cooled and have many control, operating and display elements.
Connections are made by means of easy-to-use screw terminals.
The converters are distinguished by a high degree of efficiency of > 80% and comprehensive protective and control facilities such as protection from overload and overvoltage, thermal protection and decoupling diodes. Options such as a varistor at the output, to prove additional overvoltage protection or a signal relay, further distinguish the
GWH 100 / 500 series of converters. Up to 3 units with active current sharing can be switched in parallel to extend power.
|
|
|
The revolutionary new generation of DC-DC converters, setting the standard in best-in-class topology! Highly efficient at 95%, with minimised conversion loss. Its ultra compact size reflects a super-high density. Easy mounting and connecting (plug & run), no need for auxiliary circuit design (cost & time saving), fan-less cooling = noiseless (silent) running.
|
|
Features :
- DC input active surge current limiting
- Wide 4:1~2:1 DC input range (24V: 19~72VDC, 96V:72~144VDC)
- Protections: Short circuit / Overload / Over voltage / Over temperature
/ Input polarity(by fuse)
- 2000VAC I/O Isolation
- Forced air cooling by built-in DC fan with fan speed control function
- Output OK Signal
- Built-in remote ON-OFF control
- Built-in remote sense function
- 3 years warranty
|
|
* 2:1 input range, input and output isolation
* Input under voltage protection
* Input polarity reverse protection
* Soft start function, low inrush current
* Over load, over voltage, short circuit protection
* Output voltage ±10% adjustment
* No minimum load requirement
* 100% 50°C burn-in test
* Meets UL, cUL, TUV standards
|
|
SMD-Package 1 to 15W
Our range of isolated DC/DC converters in SMD package offers products from 1 to 15W with unregulated or regulated output voltages. All models provide high pin accuracy and are qualified for automated ick-and-place machines.
They can withstand the high temperatures in lead-free reflow solder processes and comply with IPC J-STD-020C standard. All products can also be supplied in tape and reel package.
High Performance 3 to 150W
We offer an extensive range of high performance DC/DC converters with output power ranges from 3 to 150W, offering excellent specifications and very high power density in shielded metal packages. Models with wide 2:1 or ultra-wide 4:1 input ranges are available. All product series models offer an extended operating temperature range of -40 to +85°C and are available with optional
heatsink.
|
|
Compact DC/DC converters for DIN rail and wall mounting
At 100 Watt and 500 Watt the latest DC/DC converters from Zentro Elektrik extend the existing comprehensive range of converters.
The compact DC/DC converters are designed for applications in automation engineering, power supply and power station engineering, in traffic systems and railway in particular, and in mechanical engineering. They are air-cooled and have many control, operating and display elements.
Connections are made by means of easy-to-use screw terminals.
The converters are distinguished by a high degree of efficiency of > 80% and comprehensive protective and control facilities such as protection from overload and overvoltage, thermal protection and decoupling diodes. Options such as a varistor at the output, to prove additional overvoltage protection or a signal relay, further distinguish the
GWH 100 / 500 series of converters. Up to 3 units with active current sharing can be switched in parallel to extend power.
|
|
Features :
1000VDC I/O isolation
Internal SMD technology
Input filter : Capacitor type
Non-conductive plastic case
Dual in line package
SIP package is available
100% burn-in tets
Low cost/High reliability
1 year warranty
|
|
* Input / output isolation
* Input polarity reverse protection
* Input protection: fuse 12A/250V
* Input under voltage protection 74V
* Short circuit protection: shut down & auto recovery
* Over load protection: shut down & auto recovery
* Over voltage protection
* 100% 50°C burn-in test.
|
|
|
Isolated, high quality, highly reliable DC-DC converters for distributed power applications with direct soldering (lead free) onto PCB according to ROHS directives. Vertically and horizontally positioned pins makes it easy for SMD production. Power ranges from 1.5 - 10W, available with wide input 4:1. This family can cover a range of 4,5- 72Vdc. Due to vertical placing, the OTQ-series, especially, is an excellent space saver with an output range of 5- 24Vdc in both single and multioutput. Applications include: LED, LCD, and TfT displays, info-panels, portable devices, IT & Telecom and gaming machines. This model has most of the same technical features as ETA’s OBQ-series.
|
|
|
|
|
|
Absopulse Electronics offers a line of plug-in (Eurocard) DC/DC converters designed for railway and other harsh-environments. These units utilize field-proven topology to deliver any DC output up to 130Vdc. They can typically be operated from supply voltages of 24Vdc ((14.4–37V), 36Vdc (22–55V), 48Vdc (28V-74V), 72Vdc (42V-110V), 96Vdc or 110Vdc (57V-168V). Other inputs are available on request.
Absopulse’s line of plug-in (Eurocard) railway converters are designed to meet the requirements of EN 50155 for electronic equipment used on railway rolling stock. They also meet EN 55022 Class B EMI and EN 50121-3-2 (EMI and EMC). The plug-in (Eurocard) series is rated for operation over a -25 to +70oC temperature range without derating, with natural convection cooling. Features typically include full electronic protection on the input and output, optocoupler, optional alarm output and optional control input. An optional built-in redundancy diode to allow for parallel connection to achieve higher output power or N+1 redundancy is available on most designs.
These compact plug-in modules are typically used in 19” rack-mount applications. They are heavily ruggedized and conformal coated and designed to meet IEC 61373 Categories 1 A & B shock and vibration standards.
Absopulse Electronics provides an extensive range of power supplies for operation in railway, industrial and other extreme environments in encapsulated or vented, chassis mount packages. If our standard designs do not meet your requirements, our engineering team will provide a cost-effective solution to meet your exact specifications.
|
|
|
|
|
|
Absopulse Electronics’ RWY Series of encapsulated DC/DC converters are designed for operation in railway, industrial and other harsh environments. These designs are based on field-proven topology with excellent track-record in hundreds of applications. Typical input ranges available are 24Vdc (14.4–37V range), 36Vdc (22–55V), 48Vdc (28V-74V), 72Vdc (42V-110V), 96Vdc or 110Vdc (57V-168V). RWY designs for almost any output power requirements from 15W to over 280W are available, with either single or dual outputs.
The RWY Series power supplies are designed to meet the requirements of EN 50155 for electronic equipment used on railway rolling stock. They also meet EN 55022 Class B EMI and EN 50121-3-2 (EMI and EMC). These converters are entirely potted with a thermally conductive MIL-spec. silicon rubber compound for resistance against shock, vibration, humidity, moisture, dust and insects and are designed to meet IEC 61373 Categories 1 A & B shock and vibration standards. The RWY converters are conduction cooled via a base plate and rated for operation over a -40 to +70oC cold-plate temperature range without derating. The use of components with many years of established reliability and generous headroom results in a high demonstrated MTBF.
Absopulse Electronics provides an extensive range of power supplies for railway, industrial and other extreme environment applications. If our standard designs do not meet your requirements, our engineering team will provide a cost-effective solution to meet your exact specifications.
|
|
|
|
