Duplex rollers are suitable for compacting thin layers on granular soils and asphalt. They are mostly used for small jobs, repair work and compaction in confined areas.
|
|
|
A choice between two amplitudes optimises our fully hydraulic hand-guided vibratory rollers for use on asphalt as well as unbonded layers. Complete side clearance allows direct compaction along vertical obstacles.
|
|
In addition to its excellent compaction performance, the HV series offers:
Small wall clearance and ample curb clearance on each side, allowing the closest possible approach in confined areas or around obstacles.
Both drums driven by respective hydraulic motor with built-in reduction unit, eliminating the need for regular periodic adjustments that chain driven rollers require.
Vinyl-coated steering handle assures firm grip. Coating also provides heat insulation.
Semi-transparent plastic sprinkler tank permits at-a-glance checking of water level and eliminates spray nozzle clogging due to rust.
Safety provisions:Reliable pinch protection device, positive pin-lock brake and horn switch.
|
|
|
The double drum vibratory series is designed as low maintenance model for high productivity and ease of service. Each model is equipped with a water sprinkling system for asphalt compaction. They are also ideal on granular materials, non-cohesive and cohesive soils. The water tank are made from stainless material (V2A) to prevent rust and guarantees maximum use and stability. The exciter shaft bearings are lifetime oil-splash lubricated.
|
|
Walk-Behind Tandem Drum
Double-drum rollers easily tackle large asphalt compaction jobs and feature built-in water tanks, hydrostatic drive and spray bars.
|
|
|
|
|
|
VVV 600 / 12 - VIBRATORY ROLLERS
Weight kg 560
Dimensions (L x W x H) mm 2350 x 730 x 1050
Frequency Hz 60
Speed forward km/hod 0 - 5
Speed reverse km/hod 0 - 2
Max. gradability 20°
Drum width mm 600
Engine HONDA Type GX 200
Rated engine power @ RPM kW/min-1 4,6/3302
Max. engine power @ RPM kW/min-1 4,8/3600
VVV 601 / 12 - VIBRATORY ROLLERS
Weight kg 610
Dimensions (L x W x H) mm 2350 x 730 x 1050
Frequency Hz 60
Speed forward km/hod 0 - 5
Speed reverse km/hod 0 - 2
Max. gradability 20°
Drum width mm 600
Engine HONDA Type GX 200
Rated engine power @ RPM kW/min-1 4,6/3302
Max. engine power @ RPM kW/min-1 4,8/3600
VVV 601 / 12 HE - VIBRATORY ROLLERS
Weight kg 630
Dimensions (L x W x H) mm 2350 x 730 x 1050
Frequency Hz 60
Speed forward km/hod 0 - 5
Speed reverse km/hod 0 - 2
Max. gradability 20°
Drum width mm 600
Engine HATZ Type 1 B 20
Rated engine power @ RPM kW/min-1 3,5/3302
Max. engine power @ RPM kW/min-1 3,6/3600
VVV 700 / 22 - VIBRATORY ROLLERS
Weight kg 890
Dimensions (L x W x H) mm 2750 x 840 x 1250
Frequency Hz 55
Speed forward km/hod 0 - 5
Speed reverse km/hod 0 - 2
Max. gradability 20°
Drum width mm 700
Engine HONDA Type GX 270
Rated engine power @ RPM kW/min-1 6,2/2976
Max. engine power @ RPM kW/min-1 6,6/3600
VVV 701 / 22 - VIBRATORY ROLLERS
Weight kg 995
Dimensions (L x W x H) mm 2750 x 840 x 1250
Frequency Hz 55
Speed forward km/hod 0 - 5
Speed reverse km/hod 0 - 2
Max. gradability 20°
Drum width mm 700
Engine HONDA Type GX 270
Rated engine power @ RPM kW/min-1 6,2/2976
Max. engine power @ RPM kW/min-1 6,6/3600
|
|
|
Manual vibrating road roller can be used for municipal road construction, highway maintenance, and rolling work at narrow road surface, such as foundation of groove wider than 0.8m, building construction, backfilling for pipeline and gymnasium ground.
|
|
