• Light weight and compact design
• Durable glass-filled nylon reservoir and nylon
encapsulated aluminium pump base for maximum
corrosion resistance
• Two-speed operation reduces handle strokes by
as much as 78% over single speed pumps
• Lower handle effort to minimize operator fatigue
• Integral 4-way valve on P-842 for operation of doubleacting
cylinders
• Handle lock and light weight construction for easy carrying
• Large oil capacities to power a wide range of cylinders
or tools
• Non-conductive fiberglass handle for operator safety
• Internal pressure relief valve for overload protection
|
|
Hydraulic hand pumps
For loads, which cannot be lifted at the front face, or where the load capacity is to be doubled a simple formula can be used:
pump + 2 jacks = 1 jack-SET
In other words:
The separate hydraulic hand pump make up one jack SET with two or four machine jacks.
|
|
Hydratron Hand Operated Pumps feature all stainless steel wetted parts making them suitable for either oil or water service. Nine models make up the range offering output pressures of up to 25,000 PSI ( 1725 Bar ).
Single and dual piston models are available, the dual piston models having both low and high pressure pistons. This feature permits both fast fill and high pressure capabilities from one single source.
Normally we supply the pumps mounted within stainless steel carrying frames complete with 1 gal ( 4.5 Ltr ) reservoir, outlet pressure gauge and pressure release valve. In this form ( power pack ) the units contain all the necessary controls and instrumentation to carry out on site pressure tests.
Options include larger capacity tanks, larger dia test gauges, built in pressure isolation and safety relief valves. Units can also be provided mounted on wheels to provide manoeuvrebility.
|
|
Hand pumps ZPH 1A/... for single- and double-acting cylinders
LUKAS hand pumps ZPH 1A/... are robust and easy-to-operate two-stage pumps with automatic switch-over from low pressure (LP) to high pressure (HP) mode. The basic version is suitable for operation of a single-acting cylinder.
|
|
Application:
Seawater, alcohol, vinegar
Components:
• Body: bronze
• Internal mechanism: bronze
• Sealing: ramie wire mesh clamped by gland
• Connection: standardised PN 10 flange
• Lever: cast iron (brass on request)
STANDARDISED PN 10 FLANGE
Flow rate of 1.3 to 2.7 m3 / hr
|
|
|
Simplex offers the widest selection of hand pump, styles, reservoir sizs and flow rates to meet your everyday requirements. Each pump has specific features that make cetain models better suited for particular jobs.
|
|
|
|
|
|
The HP pump is a single acting hand operated pump made of stainless steel W.St.1.4301 making it particularly applicable within the food industry and in environmentally sensitive areas, designed for both oil and water hydraulics.
Application
The pump is designed for simple lifting functions and is used e.g. together with stainless hydraulic cylinders on work platforms and lifting tables or as a standby pump.
Specificationers
The HP pump is equipped with a built-in check and relief valve and is as standard. Available with built-in fluid reservoir and mounting plate.The fluid reservoir has a standard capacity of 0.7 litres, but can be made to suit individual demands.
Vertical installation
Please notice, the hand pump may only be installed in a vertical position.
Filling of reservoir
Oil hydraulics
Fill 0,7 litres of oil in the reservoir, oil viscosity 17 or 22.
Water hydraulics
Fill 0,7 litres of water (tap water) in the reservoir.
When using the pump in an area with risk of frost fill in a mix of min. 30% glycol and 70% water.
|
|
SF-OE00729/730 Standard Hand Pump
WDSSF
Technical Information 1.5 litre container Output complete cycle 25cm3 Maximum pressure (blow off) 175kgf/cm2 Effort required on handle at operating pressure of 100 bar = 22kgs
SF-OE00490/491 Dual Displacement Pump
WDSSF
Technical Information 2.9 litre container Normal operating pressure 100 bar Change over pressure 33 bar Maximum pressure (blow off) 175kgf/cm2 Effort required on handle at operating pressure of 100 bar = 18kgs
|
|
Amazon Thrudeck
c/w detachable handle and through deck kit
For mounting through deck or through bulkhead
Readily achievable 50 Litres/min (11 gallons/min) output
Features::
• The ultimate compact through deck pump with no less than 16 port variations relative to the body
• Loosening just one screw lets you clear blockages or re-position the body anywhere through 360º
• relative to the handle position
• Complete with stainless steel handle, mounting clips and provision for safety lanyard
• Sleekly styled through deck kit and cover, with 4 mounting positions relative to the pump
|
|
|
|
|
|
This pump is a descendant of the authentic Japy manual pump, which has been manufactured since 1850 in France.
This new pump complies with the European ATEX CE atex II 2 GD IICT4 (Tf<120°C) standard. It is designed to transfer the water, oil, gasoil, petrol and certain solvents in a potentially explosive atmosphere.
The pump includes a 300 micron filter in stainless steel, which protects it from all external intrusion.
It is delivered with an earth cable and a clamp, the connection of which provides electrostatic conductivity.
In the barrel emptying version, it is equipped with 304L stainless steel tube with a outlet size allowing connection to a barrel or to a tank.
It is supplied with a hose for hydrocarbons or solvents that is able to conduct static electricity.
A stainless steel valve with a stainless steel pouring lip are delivered as standard. This can be replaced by a manual dispensing pistol in nickel brass.
CAPACITY - 1.3 or 2 m3/h
BODY - Cast
MECHANISM - Brass
GASKET - PTFE
BUNG - 1m intake tube in 3/4” stainless steel, 2"
STAINLESS - steel elbow and nozzle output, conductor pipe
OTHER - Earth cable
|
|
This pump is the descendant of the authentic Japy manual pump, which has been manufactured in France since 1850.
This new pump complies with the European ATEX CE atex II 2 GD IICT4 (Tf<120°C) standard. It is designed to transfer the water, oil, gasoil, petrol and certain solvents in a potentially explosive atmosphere. The pump includes a 300 micron filter in stainless steel, which protects it from all external intrusion.
It is delivered with an earth cable and a clamp, the connection of which provides electrostatic conductivity.
CAPACITY - 1,3 or 2 m3/h
BODY - Cast
MECHANISM - Brass
GASKET - PTFE
|
|
|
|
|
|
The HP pump is a single acting hand operated pump made of stainless steel W.St.1.4301 making it particularly applicable within the food industry and in environmentally sensitive areas, designed for both oil and water hydraulics.
Application
The pump is designed for simple lifting functions and is used e.g. together with stainless hydraulic cylinders on work platforms and lifting tables or as a standby pump.
Specificationers
The HP pump is equipped with a built-in check and relief valve and is as standard. Available with built-in fluid reservoir and mounting plate.The fluid reservoir has a standard capacity of 0.7 litres, but can be made to suit individual demands.
Vertical installation
Please notice, the hand pump may only be installed in a vertical position.
Filling of reservoir
Oil hydraulics
Fill 0,7 litres of oil in the reservoir, oil viscosity 17 or 22.
Water hydraulics
Fill 0,7 litres of water (tap water) in the reservoir.
When using the pump in an area with risk of frost fill in a mix of min. 30% glycol and 70% water.
|
|
Standard supplied with Nitrile seals – can be used for a wide range of fluids such as demineralised water, oil/water emulsions, waterglycols, mineral oils
Two speed pumps up to 1000 bar pressure
Buna Nitrile seals can be exchanged with optional EPDM seal for use with Skydrol or brake fluids
Impregnated aluminium anodized pump housing with stainless steel internal pumping components
Externally adjustable pressure relief valve
Internal pressure release valve for overload protection (pump safety valve).
|
|
|
Handpumps with or without reservoir for use with corrosive liquids for pressures up to 700 bar. They are as single or two stage. Applications are for example pressure testing when there is no air connection available or backup pump in case the basic pump fails.
|
|
HYDRAULIC PUMPS
Hand pumps, Air Hydraulic Foot pumps, Electric Pumps, Ultra High Pressure Hand/Air pumps, Ultra High Pressure Air Pumps, Working pressure from 700 bar to 2800 bar.
|
|
PH - One stage hand pumps
One-stage pumps within the PH-series have a rather simple but very functional design with just a few moving parts. These pumps are real working horses that will last a very long time to come. All PH pumps can be equipped with a pressure gauge in order to have full control about the generated pump force.
PH70-500/LS201 - The pump PH70-500 is also available in a version with a pre-mounted hose of 2 m (LS201ES) including quick coupling AQI7 and swivel coupling ASE10.
*) Gauges and gauge adapters listed here are recommendations only. Gauges and gauge adapters are not part of the pump. Different combinations of gauge and gauge adapter are possible.
|
|
|
|
|
|
JESSBERGER offers hand operated drum pumps for nearly all applications:
JP-02: Hand pump for detergents and chemicals on water-basis; pump made of Polypropylene with shaft made of SS 316 and seals made of Viton; cause of its telescopic suction tube suitable for 200 l drums and smaller canisters; 0,3 - 0,45 l/ stroke.
JP-03: Hand pump for diesel, anti freezing liquid, oils, water, etc.; pump made of Polypropylene with shaft made of steel and seals made of NBR/ Buna; cause of its telescopic suction tube suitable for 200 l drums and smaller canisters; 0,3 - 0,45 l/ stroke.
JP-04: Chemical hand pump; completely made of Polypropylene, shaft coated with PP and seals made of Viton; cause of its telescopic suction tube suitable for 200 l drums and smaller canisters; 0,3 - 0,45 l/ stroke.
JP-05 (shown at the picture): hand pump for food material or flammable media; made of SS 316 and PTFE; 700 and 1000 mm, 0,3 - 0,6 l/ stroke.
Please note that we have further hand pumps in our range.
The products of this manufacturer have a very good cost/ performance ratio. The pumps have standed the test of time since many years in nearly all industries worldwide.
|
|
Hand pumps are the most common power source within the area of small and medium sized hydraulic cylinders. Longlife and a outstanding suction properties features this robust and full-metall-construction. Carrying handle and ventilation screw as well as many other details are part of the delivery package.
Features
- Operating pressure max. 700 bar.
- Two stage operation with automatic switch-over (except HPS-1/0.7 A).
- Large reservoir volumes.
- With pressure relief valves, adjustable from the outside.
- Fine adjustable relief valve (handwheel).
- Robust all-steel construction.
- HPH pumps are equipped with a 4-way control valve plus a precision-adjustable relief valve
- Oil port thread: 3/8 NPT.
- Incl. oil filling.
- Pressure gauges with corresponding adaptors are also available as accessories.
|
|
