Small programmable compact Infrared temperature measurement instrument for manifold industrial applications with a very short response time and a minimal measuring spot of only 7 mm.
Features:
- 2 Outputs (V, mA, Thermelement J, K) for sensor and object temperatures
- Programmable Temperature Measurement Instrument
- Small dimensions of the infrared sensing head -
- separate sensing head and electronics
- Ambient temperature sensing head -20°C...+180°C
- Output programmable (mA, V, Thermocouple J, K)
- LCD Display
- Programming keys for parameter adjustment
- Spectral range of 8 - 14 µm for general measurement tasks in the range of
- -40°C...+900°C
- Measuring range, emissivity, transmissivity adjustable
- MIN, MAX, mean values and HOLD feature adjustable
- Reduction of the measurement spot with the aid of focussing optics
See more information in our shop:
***www.temperature-shop.de***
|
|
With our new PYROSPOT Series 10 and 40 we can now offer you digital pyrometers with very good characteristics for nearly every industrial application.
Several temperature measuring ranges from -30 °C up to 3000 °C, different spectral ranges, vario optics and fibre optics, analogue and digital standard industrial outputs, and robust housing with easy connecting abilities characterise our new devices.
All our pyrometers can be easily integrated in system solutions or adjusted to the appropriate application by using our comprehensive range of accessories. |
|
| A gold plated parabolic mirror focuses the measured spot on to itself. Thus IR radiation is captured between object and mirror. Due to multiple reflections the radiance in this area is up to 15 times higher than without mirror. |
|
Non-contact temperature measurement is a standard technology in industrial manufacturing and in engineering processes. In glass manufacturing, metal working or food production, accurate temperature measurement is the crucial dimension to be considered during processing and monitoring.
IMPAC Infrared offers a broad variety of pyrometers – including the products of Mikron Infrared Inc., USA. – covering nearly all applications. The use of the correct device essentially depends on the material of the object to be measured, the expected temperature range and the mechanical conditions.
For detailed information please see:
Pyrometer overview IMPAC
www.impacinfrared.com/EN/products/pyrometer/pyrometer.html
Pyrometer overview Mikron
www.mikroninfrared.com/products/Products-s1-process.htm |
|
Raytek has introduced the new Raytek XR infrared (IR) thermometer. Designed to optimize continuous temperature monitoring in a broad range of manufacturing processes, this advanced sensor is a rugged, IP65 sealed single-piece system with the flexibility to handle almost any application. The Raytek XR thermometer combines a host of best-in-class features, including multiple extended temperature ranges, precision temperature resolution, RS-485 outputs and a versatile electronics platform. The sensor provides a flexible, user-defined analog output that can be matched with almost any existing control system. An intuitive local user interface simplifies system setup and configuration, and adds powerful troubleshooting capabilities. The Raytek XR thermometers, with multiple measurement ranges, utilize identical, configurable installation hardware and application software. Users have the freedom to choose the easiest or best means of wiring the sensor for a given application. In addition, standard RS485 communications enables remote configuration—streamlining troubleshooting and data acquisition.
Industries and processes for the use of the Raytek XR pyrometer are:
· Glass Surface Temperature Measurement
· Plastics Processing
· Printing, Paper, Textile
· Construction Materials
· Hot Metal Detection
|
|
Features:
Temperature range 50°C to 400°C
Calibration and control of pyrometers
Digital control, control accuracy 0.1 K
Control parameter adjustable
Isothermie from 0.1°C, better than 1°C
Cavity aperture 25 mm |
|
B&B Thermo-Technik GmbH offers Infrared Thermometers for various applications:
- a simple and favourable Infrared Thermometer FlashBeam 8869
for 56,- Euro net (price 2006)
with Laserpointer
Measuring range: -20°C to +420°C
Response time: 500 ms
Resolution: 1°C
Distance Spot ratio: 8 : 1
- Favourable Infrared Thermometer Flashbeam 8866
with laserpointer
with emissivity selectable
with many features
- Infrared Thermometers especially developed for the temperature control
of food
- Infrared Thermometer with RS232 Interface
and many features
Please find further information in our Temperature Shop:
www.temperature-shop.eu
In the Temperature-Shop you will also find information about our range of:
- Temperature Probes
- Temperature Humidity Sensors
- Thermocouple Connectors
- Temperature Measurement Instruments
- Infrared Thermometers
- Hygrometers
- Data loggers
- Recorders
- Stationary Pyrometers
- Controllers
- Indicators
- Transmitters |
|
Functions
The different models of the series measure temperatures between 50 °C and 2500 °C.
Response times from 5 ms up to 100 ms allow adaptation to fastest processes.
Integrated aiming options with LED for optimal alignment ...
... or aiming with the view finder.
Focus lenses can be adjusted to any measuring distance.
Fibre cable optic with lenses are used wherever ambient temperature is high or small mesuring heads are necessary.
Features
Very high temperature resolution from 0.2 °C
Smallest field-of-views from 1 mm allow high optical resolution. |
|
Portable infrared pyrometers are battery driven portables for non-contact temperature measurement. Depending on the material of the measuring object and the expected temperature range, IMPAC Infrared offers the following products:
Series IN 14 and IN 15: Measurement on non-metallic surfaces or coated, painted or anodized metals from -32 to 900°C.
IGA 15 plus: Measurement on metals, ceramics, graphite etc. from 250 to 1800°C.
Series 15/5: Measurement on glass surfaces from 150 to 1800°C.
Series 8: Very fast (1ms) measurement on metals of glass surfaces from 600 to 2500°C. Special versions for the measurement of pouring streams or for measurements in coking plants are available.
Mikron Series M90: Full blown product family including e.g. ratio pyrometer versions for various applications.
For detailed Information please see:
Portable pyrometers IMPAC:
www.impacinfrared.com/EN/products/pyrometer/portables.html
Portable pyrometers Mikron
www.www.mikroninfrared.com/products/Products-s7-portables.htm
|
|
The IR-CA Product Line of Non-Contact Infrared Thermometers provides broad selection of units to match your applications and requirements for non-contact temperature measurement. The product line consists of 15 different Series grouped into General Purpose and Application Specific models.
Low Temperature – Long Wavelength: IR-CAB
Low Temperature – Short Wavelength: IR-CAE
Low to Medium Temperature and Small Spot Size: IR-CAP
Medium Temperature – Wide Temperature Range: IR-CAI
High Temperature – Wide Temperature Range: IR-CAS
Multi-Wavelength – Multi-Function: IR-CAQ
World’s Widest Temperature Range Infrared Thermometer: IR-CAW
Polyester Film: IR-CAN
Polyethylene Film: IR-CAM
Measurement Inside of Furnace: IR-CAR
Glass Temperature: IR-CAG
Semicon/Silicon: IR-CAT
Semicon/InGaAs: IR-CAU
Food Industry: IR-CAFX
|
|
Thermophil INFRAsmart R300/ R301/ R302
Compact, sturdy pyrometer
integrated electronics up to 70 °C
Two-wire techniques 4 - 20 mA
Hart interface
Spectral range for plastic, glass, metal
Optic options for different measures
Punctual temperature registration with good price-/performance ratio
|
|
Blackbodies are reference sources used for testing infrared systems. They are required in industry for calibration of pyrometers, infrared line scanners or cameras.
In Defence, they are part of benches for characterisation of complex optronic systems. HGH offers a wide range of blackbodies to cover all Customers’ needs:
- DCN 1000N Differential blackbody for characterization of infrared system performances
- RCN High temperature cavity blackbody for calibration of infrared sensors
- ECN 100 Extended area blackbody for field tests and calibration without collimator
- DCN 1000L Low temperature blackbody
- DCN 1000N Vacuum cryogenic temperature blackbody for space borne systems testing
In addition, HGH have the ability to design specific infrared sources on request.
In many cases, blackbodies are associated to test targets/target wheels and incorporated into infrared collimators (IRCOL).
Contact us with your specifications. |
|
- Noncontact temperature measurement from -35°C up to 900°C
- Worlwide patented features: crosshair laser sighting for standard applications with the option to switch into close focus mode
- crosshair laser sighting marks real spot size at any distance
- close focus mode for spot sizes as small as 1 mm
- 75:1 optics
- USB interface and graphic software with oscilloscope function for 20 data per second
- flip display switches into most convenient viewing position |
|
Many customer requests and special applications require non-contact temperature measurement solutions which challenge IMPAC beyond the conventional. As a consequence IMPAC has developed numerous special pyrometers, optimized for the specific demands of a wide range of industries and applications.
Examples are:
- Pyrometer series’ using two-colour technology (ratio pyrometers) for hostile environments.
- Pyrometers for the measurement on special materials (e.g. aluminium (IS 12-AL), flame measurement (IPE 140/45), glass, measurement in coking plants (IS 8-K plus), PE and PP foils (IPE 140/34), silicon (IS 12-Si), etc.).
- Pyrometers to measure a pouring stream of metals or alloys (IS 8 GS plus, ISR 12-LO/GS).
- Pyrometers with an integrated scanner to detect anomalies.
- Pyrometers with automatic calculation and correction of the emissivity (Quantum I, Mikron Infrared).
-Temperature switches (for fast hot object detection to trigger a process).
IMPAC also offers the development of customer specific instruments on request.
For detailed Information please see:
Pyrometers IMPAC
www.impacinfrared.com/EN/products/pyrometer/pyrometer.html
Pyrometers Mikron
www.mikroninfrared.com/products/Products-s1-process.htm |
|
For extremely fast applications (up to 5 µs) IMPAC offers pyrometers of the KLEIBER High Speed Line and consequently can provide solutions for applications dealing with fastest processes. KLEIBER pyrometers feature the same excellent technical properties as IMPAC standard pyrometers, but with much shorter response times.
These pyrometers are typically used in the field of laser applications and in material research and development.
Moreover IMPAC offers measuring stations from KLEIBER. These contain a power supply, a digital display and a pyrometer. PID-controllers can also be integrated as an option.
An example for such a measuring station is the KS 740 HS-USB which features fastest response times with an online USB data transfer to a PC (including the needed analysis software).
For detailed information please see:
www.impacinfrared.com/EN/products/pyrometer/kleiber-highspeed.html
respectively:
www.kleiberinfrared.de
|
|
Mikron’s lines of E˛T infrared thermometers provide reliable temperature measurement in the Petrochemical Industries. The offered product series’ are each designed for special applications in this area.
The Pulsar II series is designed for temperature measurements of High Temperature, Sulphur Recovery and Sulphur Burning Furnaces. These instruments measure the temperature of gas, refractory or a combination of both temperatures.
The Quasar line of products is designed for continuous Flare Stack Monitoring of Pilots, Flaring and Smoke. They suit for a monitoring distance of up to 400 m.
Both systems are CSA, CENELEC and ATEX certified for hazardous areas. |
|
- Temperature range from minus 40 °C to 600 °C (minus 40°F to 1112°F)
- Highest in its class ambient operating temperature up to 180°C/356°F
- Highest optical resolution in its class
- Halogen and Silicon Free - Environmentally-friendly Cable
- Miniature sensor that fits anywhere
The Raytek MI is a two-piece infrared temperature measurement system with a miniature sensing head and separate electronics. The miniature sensing head is small enough to be installed just about anywhere, but performs as well as much larger and more expensive systems. The MI measures target temperatures ranging from -40 to 600°C (-40 to 1112°F). Easily adjust the MI signal processing electronics, which include Emissivity, Peak Hold, Valley Hold, and Averaging functions, on the 5-digit LCD user interface. |
|
Fast and reliable non-contact temperature measurement
Temperature Range from -20 to 3000 (see table below)
/0F selectable
Various Sighting Modes: Laser, Coaxial Laser, Telescope
Adjustable Emissivity, Backlight
Tolerance Alarm
Display of Max., Min., T, Avg. and real time value
Display hold, Wide Application |
|
The ultra compact Pyropen has been specifically designed to fit into your pocket, just like a pen, so that you can carry it with you anywhere you go.
You simply aim, press the SCAN button and read the temperature immediately. No fuss. No need to focus and no special training.
The non-contact nature of the measurement means that you can take the temperature of moving, rotating, inaccessible or hazardous objects. This makes the Pyropen particularly useful for test, inspection and maintenance applications in industries such as food & beverage, automotive, plastics & rubber, textiles, paper & packaging, chemicals & pharmaceuticals, HVAC, electrical, asphalting, plus many others.
The Pyropen L has all the features of the Pyropen E, plus laser sighting for small or distant targets and adjustable emmissivity.
The Pyropen D has all the features of the Pyropen L, plus a built-in memory for logging up to 12 temperatures and the ability to perform PC based data acquisition. It is supplied complete with PC interface cable and Calexlog
software disk. |
|
Compact thermometer with wide temperature range
* Measures temperature from -58 to 1000°F with 0.1° resolution up to 199.9°
* Built-in laser pointer identifies target area
* Backlighting illuminates display for taking
measurements at night or in areas with low
background light levels
* Overrange indicator
* Automatic Data Hold when trigger released |
|
The Fluke 570 non-contact thermometers are ideal professional diagnostic tools for maintenance professionals requiring the most accurate temperature readings at all distances. The Fluke 570 series infrared (IR) measures surface temperatures, helping to quickly locate lubrication problems, overloads, short-circuits or misaligned and overheated equipment, reducing work and follow-up time, and improving performance.
From close-up electrical connections, to distant room balancing checks, the Fluke 570 series can take IR temperature measurements with ease. Predictive maintenance professionals requiring analysis and documentation use the 574 or 576 models, with 100-point data logging and digital photographs (576-only) with the included software for graphing and analysis for follow-up reporting and documentation.
|
|
thermoMETER MS series: Intelligent universal infrared thermometer
The optris MS series combines state-of-the-art technology with an attractive price.
A wide temperature range of -32 to 760 °C, laser aiming and an optical resolution of 20:1 allow technicians to carry out accurate non-contact surface measurements for electrical and mechanical maintenance, HVAC checks, automotive testing and other applications, in fast anywhere that temperature is a factor.
optris MiniSightPlus: 'OFFSET' and 'HOLD' make measurements smart. Object emissivities can be adjusted even after the measurement is taken. |
|
Portable noncontact thermometers have become indispensable tools for many predictive maintenance and industrial troubleshooting applications. These fast and reliable tools are famous for their rugged, ergonomic designs and affordable prices.
3i Series Dedicated infrared thermometers for specialty applications.
Fluke 60 Series The professional's diagnostic tool.
(formerly ST Series)
Fluke 570 Series The precision thermometer for vital analysis.
(formerly MX Series)
|
|
When it comes to temperature measurement technique and provided that a combination of simplest control and high measurement accuracy is required, then infrared-thermometers will always be the first choice.
This choice becomes a must, if one of the following requirements are given:
- Deterioration-free measurement of moving components
- Measurement of dangerous matter (e.g. electrically life parts, chemically aggressive materials etc.)
Measurement in inaccessible locations
Feedback-free measurement of small low-mass components
without infrared-thermometers is almost unthinkable.
In this case, nothing is easier as operation according to the motto:
targeting – measuring – reading the measurement value.
In any area of non contact temperature measurement, SIKA infrared-thermometers are reliable partners due to the following features: fully developed laser sight technology, very good optical characteristics, and modern technology with adjustable emissivity, data memory, and numerous additional functions.
|
|
SKF Dual Laser Infrared Thermometer TMTL 2400K
The SKF Dual Laser Infrared Thermometer TMTL 2400K can be used as both a contact and non-contact thermometer. The object’s temperature can be measured using the infrared detector or a probe.
Lightweight and compact, the TMTL 2400K can safely measure the temperature of hot, hazardous or hard-to-reach objects without contaminating or damaging the object’s surface. The optics of the TMTL 2400K sense emitted, reflected and transmitted energy, which is collected and focused onto a detector. The TMTL 2400K’s electronics translate the collected information into a temperature reading, which is displayed in °C or °F. The built-in dual-laser feature and spot ratio of 50:1 helps enable exact pinpointing of the temperatue measurement area.
The TMTL 2400K enables contact temperature measurement and allows the emissivity to be user selected. This allows the contact temperature measurement to be easily compared with the infrared measurement in order to find and adjust the thermometer emissivity for accurate infrared measurement of the same measured object.
-Can be used as infrared thermometer and/or contact thermometer with supplied K type temperature probe
-Non-contact measurement makes it possible to safely measure the temperature of hot, hazardous or hard-to-reach applications
-Wide measurement range using infrared sensor from -60 to 1000 şC (-76 to 1832 şF), with probe -64 to 1400 şC (-83 to 1999 şF)
-Distance/spot ratio of 50:1
-User selectable variable emissivity between 0,1 and 1,0
-White LED Flashlight to help visualize the application
-Large backlit display
|
|
°C, %rF
•Switchable optics for far-field measurements (75:1) and close focus (1 mm, 70 mm distance)
•Especially bright cross laser sighting for indicating the actual measuring point
•Reference accuracy ± 0.75 °C with super-fast measurement technololgy (scanning 100 ms)
•Backlit display (3-line), shows °C, min./max. values, alarm limit values and emissivity; in addition display with humidity module: %RH, °Ctd
•Optical and audible alarm when limit values are exceeded
•Instrument memory for 90 measurement protocols
•PC software for archiving and documenting measurement data (included in delivery)
•Tripod fitting for online measurement via USB cable (included in delivery) |
|
Description
The TM8-IR temperature measuring instrument is a non-contact infrared
thermometer with laser aim and large, backlit LCD display. Infrared
thermometers are particularly suitable for measuring surface temperatures.
The special benefit is the short response time (less than a second)
without having to come in contact with the measured object. Therefore,
the instrument is particularly suitable for moving (e.g. paper reels, tyres) or
live (e.g. electrical assemblies, transformers) parts. Also for measurements
in the food industry, because the medium is not polluted by a sensor.
An additional NiCr-Ni thermocouple can be connected to the instrument. |
|
Our Mini-Flash is very simple to use: To measure a temperature point unit at object, pull the trigger and read the measuring value from the display. The Mini-Flash is used for easy and quick measurements on surfaces.
Features:
- C°/F°- switchable
- 2-line Display for actual and maximal temperature
- Automatic Hold
- Lock-mode for continu | | |
